38 OHM875VD / OHM1075VD / OHM1575VD
English
9. SPECIFICATIONS
OHM875VD OHM1075VD OHM1575VD
Power supply (car battery) 12V DC (10V-16V)
Test voltage 14V, negative ground
Operating current <1.3A <1.5A
Current consumption <6mA
Max current consumption <1.8A <2A
Mechanism Manual open and close
Video system Auto, NTSC and PAL
Screen 8” diagonal 10.2” diagonal 15.4” diagonal
Resolution 800 x 480 1024x768
Display angle Vertical adjustable up and down; maximum angle 180°
Viewing angle (up/down/left/right) 45/65/65/65 10/30/40/40
Weight 4.313 lbs (1.95 kg) 4.959 lbs (2.25kg)
Video signal 1Vp-p, 75-Ohm load
Operating temperature -5 ~ 55° C
Storage temperature -20 ~ 70° C
Dome light 2W
Note:
For the sake of technical improvements, this technical data and
the design of the equipment may change without prior notice.
