VRX765VD
280-8358-00
English
INSTALLATION AND WIRE
CONNECTION MANUAL
8. WIRE CONNECTION
iPod
(CCA-670-600)
CeNET
terminal
Yellow
TV tuner input terminal or
DVD changer input terminal
Optical output
connector
Radio antenna jack
Connector cable
4-Channel Amplifier
• Before installing, be sure to disconnect the negative cable of the car battery.
• In the optional devices, the RCA Pin and the Connector cable are separately-sold items.
N
ote:
Red
White
Red
White
Right
left
Front audio output
terminal
Right
left
Rear audio output
terminal
Right
left
Non fader
output terminal
Gray
Black
Purple
Red
White
Yellow
Yellow
White
Red
Video output terminal
Video
Audio (left)
Audio (right)
Visual input
terminal
Wireless
Head phone
VTR etc.
Right
Left
(2-ZONE
output terminal)
Gray
Rear monitor
Black
Red
Green
Red
White
