Features and Specifications
Congratulations
• LED Light Bar with Hold or Scan
• Soft turn on/off circuit
• Variable gain control
• Remote turn on/off
• Hi/low level inputs
• Power on LED indicator
• Fully adjustable electronic crossover network
• Remote control Bass boost ( 0 – +18dB @ 60Hz )
• 2 ohm stereo stable
• Bridgeable into 4 ohms
• MOSFET PWM power supplies
• LED protection indicator
all amps feature:
table of contents
USER MANUAL
SPECIFICATIONS
LA438/538/738/938/1438/1838/2038
FEATURES & CONTROLS
LA638/838/1038 FEATURES & CONTROLS
ELECTRICAL WIRING, INSTALLATION & SETUP
2 CH STEREO INPUT CONNECTIONS
4 CH STEREO INPUT CONNECTIONS
BRIDGED INPUT CONNECTIONS
BASIC STEREO SPEAKER CONNECTIONS
MONO-BRIDGED SPEAKER CONNECTIONS
TROUBLESHOOTING
WARRANTY
1
2
3
4
5
6
7
9
10
11
13
Legacy amps are some of the most advanced car amplification products
available. These quality audio products are designed and engineered to afford
you years of uncompromised musical service. Legacy has utilized the latest
electronic technologies in order to deliver a superb listening experience.
This innovative system has been designed utilizing a 12 V DC Negative Ground
power supply. The LEGACY Series amps incorporate two to eight MOSFETS
in the different models.
This design produces enough available voltage to supply the main amplifier
sections, and still have a huge amount of reserve voltage for peak “high
demand” situations.
The Legacy line has been designed to ensure adequate headroom for even
the most demanding peaks and dynamic ranges found on today’s CD’s and
recordings. Used properly, these amplifiers will provide you with years of
listening pleasure.
Specifications
OUTPUT POWER
RMS @ 4 OHMS
RMS @ 2 OHMS
MAX OUTPUT
BRIDGE MODE
FREQUENCY RESPONSE
INPUT IMPEDANCE
LOW LEVEL INPUTS
HIGH LEVEL INPUTS
INPUT SENSITIVITY
LOW LEVEL INPUTS
HIGH LEVEL INPUTS
POWER SUPPLY VOLTAGE
MATCHING SPEAKER IMPEDANCE
STEREO MODE
BRIDGED MODE
MAXIMUM CURRENT DRAW
DIMENSIONS, W x H x L, inches
(mm)
NET WEIGHT, LBS (KG)
LA438/538/638/738/838/938/1038/1438/1838/2038 also feature
:
LA
438
2CH amplifier
LA
538
2CH amplifier
2 X 40W
2 X 60W
2 X 300W
1 X 600W
10Hz-30 kHz
10 k-Ohms
100 Ohms
250 mV
2.5V
14.4 VDC/NEG GD (10.5-16V)
2-4 OHMS
4-8 OHMS
15 A
11 X 2.7 X 8.25
(279 X 69 X 209)
5.7 (2.5)
LA
638
4CH amplifier
4 X 35W
4 X 55W
4 X 250W
2 X 250W+500W
OR 2 X 500W
2-4 OHMS
4-8 OHMS
20 A
11 X 2.7 X 12
(279 X 69 X 305)
8.1 (3.7)
LA
738
2CH amplifier
2 X 75W
2 X 125W
2 X 500W
1 X 1000W
2-4 OHMS
4-8 OHMS
20 A
11 X 2.7 X 12
(279 X 69 X 305)
7.5 (3.4)
LA
838
4CH amplifier
4 X 50W
4 X 75W
4 X 400W
2 X 400W+800W
OR 2 X 800W
2-4 OHMS
4-8 OHMS
30 A
11 X 2.7 X 15
(279 X 69 X 381)
9.5 (4.3)
LA
938
2CH amplifier
2 X 90W
2 X 150W
2 X 600W
1 X 1200W
2-4 OHMS
4-8 OHMS
30 A
11 X 2.7 X 13.5
(279 X 69 X 343)
8.4 (3.8)
LA
1038
4CH amplifier
4 X 75W
4 X 115W
4 X 500W
2 X 500W+1000W
OR
2 X 1000W
2-4 OHMS
4-8 OHMS
40 A
11 X 2.7 X 17
(279 X 69 X 432)
10.6 (4.8)
LA
1438
2CH amplifier
2 X 125W
2 X 200W
2 X 800W
1 X 1600W
2-4 OHMS
4-8 OHMS
30 A
11 X 2.7 X 15
(279 X 69 X 381)
9.2 (4.2)
LA
1838
2CH amplifier
2 X 150W
2 X 225W
2 X 1000W
1 X 2000W
2-4 OHMS
4-8 OHMS
40 A
11 X 2.7 X 17
(279 X 69 X 432)
10.6 (4.8)
LA
203
8
2CH amplifier
2 X 200W
2 X 300W
2 X 1200W
1 X 2400W
2-4 OHMS
4-8 OHMS
50 A
11 X 2.7 X 19
(279 X 69 X 482)
11.4 (5.2)
on your purchase of a new
American Legacy amplifier !
American Legacy Amplifier Features
2 X 50W
2 X 75W
2 X 400W
1 X 800W
2-4 OHMS
4-8 OHMS
15 A
11 X 2.7 X 9.25
(279 X 69 X 235)
6.2 (2.8)
