5
Function Description
Icon Function Function Description
Brightness
This function increases or decreases the brightness of the image.
Contrast
This function increases or decreases the difference between the dark and light
color.
H-Position
This function shifts the entire display image left or right.
V-Position
This function shifts the entire display image up or down.
Phase
A total of 32 scales (0 to 100) are available to adjust the focus and clarity of
the display.
Clock
This function carries a frequency tracking feature that offers the user to have
better stability and clarity. Increasing Clock value can be up to +127 scales.
The number of decreasing Clock (minus) is depend on the input timing.
Auto Adjustment
This function will adjust the display size automatically to fit full screen.
OSD H-Position
This function moves the OSD menu window left or right.
OSD V-Position
This function moves the OSD menu window up or down.
Graph Text
This function is to choose a display that allows maximum graphics text
quality. The resolution selection can either be 640 x 400 or
720 x 400. Please refer to Chapter 3 “ Standard Timing” Table for of
different timing modes.
Recall
The recall function will return all adjusted parameters to factory preset
values.
Language
Five OSD language options are available:
English, German, French, Spanish and Italian.
Press the left or right Adjustment Control button to select other language.
Color
Temperature
Color Temp.: Push the (+ -) button to select a different color temperature.
Please see the diagram below for function and description.
Save Exit Saves the values of this setting and exits the OSD menu function.
Icon Function Description
9300
CIE coordinated Color Temperature of
9300°K
Sets the CIE coordinate color temperature to
9300°K
SRGB
CIE coordinated Color Temperature of
SRGB°K
Sets the CIE coordinate color temperature to
SRGB°K
User
Three colors (Red, Green, Blue) can be
adjusted from the OSD menu
Sets the settings to a by user defined CIE
Temperature.
