Features And Controls
7
Installation
34
Caution
Do not bring magnetic devices
such as credit cards or magnetic
cards near the monitor.
.
.
.
.
X
POWER Button
MENU Button
PLAY/PAUSEButton
1. Open the package and check that these items are presents.
INSTALLATION PLATE
UNIT
SCREW A SCREW B
2. Connect the external compoments to the RCA cable or AV output.
(Refer to the connection diagram on page 33)
3. Match the position of installation bracket and
installation plate with screw A.
4. Tighten the unit with the supplied
screw B.
EJECTButton
Discloadingslot
Audio Video
AV2Inputs
Reset
AV SelectButton
+/- Buttons
Dome LightButton
Skip Forward/BackButton
SDInput USBInput
SD
USB
