BASIC OPERATION
10
1.PWR BUTTON
Press it to turn on the unit. Press it again to turn off.
In RADIO mode, press the BAND button on the front panel or on the remote
controller to select your desired radio band and word which band is selected
will be displayed on LCD. Press it to change the bands as below :
4.BAND BUTTON
FM MW LW
For 3 Bands(Europe)
FM MW
For 2 Bands(Europe)
FM AM
For 2 Bands (USA)
2-3.VOL+/VOL- & SEL BUTTON
Press sel button repeatedly to change mode through volume, bass, treble,
balance, fader, color, bright, contrast and tint modes. Face up or down swing the
SEL knob VOL + /VOL- to adjust the selected mode.
(The corresponding value will show on the display.)
When mode has not been adjusted for several seconds, display returns to normal
radio or CD display.
Adjust volume level by using VOL + / VOL - button.
Note: The unit is initially set to volume mode.
Press SEL button one time. Adjust bass level by using VOL + / VOL -
button.
A.Volume:
B.Bass:
C.Treble:
D.Balance:
E.Fader:
Press SEL button two times. Adjust treble level by using VOL + / VOL -
button.
Press SEL button three times. Adjust sound balance between left
and right speakers by using VOL + / VOL - button.
Press SEL button four times. Adjust sound balance between front and
rear speakers by using VOL + / VOL - button.
Tint Contrast Bright Color
Volume Bass Treble Balance Fader
( : the function of the Color, Bright, Contrast and Tint. Please see 14 page.)NOTE
5.EQ BUTTON
Press it to turn to equalization function and to select desired audio mode.
There are four kinds of mode as below:
JAZZ CLAS POP ROCK
1
14
13
12 21
619
7
23
16
4
22
10 9
20
51518
17
24
3
211
8
25
SEL
