BASIC OPERATION
14
REAR VIEW CAMERA
When connecting the rear view camera.the mirror image of the rear view through
the rear view camera is automatically displayed on the monitor when you change
the gear to the back position.(The monitor on the unit only.)
if the parking brake is not engaged,“parking brake” flashes on the monitor,
and no playback picture will be shown.only the audio will be heard.
-This warning appears only when the parking brake wire is connected to the parking
brake system built in the car. (See page .7)
NOTE(for the brake function)
COLOR: 0 to 32
Adjust the color fo the picture-lighter or darker.
BRIGHT:0to32
Adjust if the picture is too bright or too dark.
CONTRAST: 0 to 32
Adjust the contrast of the bright ans dark portion.
TINT:0to32
Adjust the tint if the human skin color is unnatural.
-Adjustable when “NTSC is selected for NTSC/PAL“““.
(The function of the VOLUME, BASS,TREBLE, BALANCE and FADER, Please
see page 10.)
2.ADJUSTABLE ITEMS:
TFT MONITOR OPERATION
1. Press the SEL button(3) repeatedly during DVD/VCD mode to display the adjustment
items on the screen(24). and then face up or down swing the VOL+/- buttons to adjust
the selected item.
(The corresponding value will show on the display.)
Tint Contrast Bright Color
Volume Bass Treble Balance Fader
AUX INPUT JACK
When the unit connect external A/V (See number 23), you can press MODE to
switch the AUX input mode.
