c. 19” security monitor
V191 BN Series
Panel Type:
Size:
Pixel Pitch:
Brightness:
Contrast Ratio:
Response Time:
Viewing Angle(H / V)
Max. Resolution:
Display Color
Active TFT-LCD
19” diagonal
0.294 (W) ×0.294 (H) mm
Typical: 270 cd/
Typical: 700:1
Typical: 8 ms
Typical: 150°/135°
1280 (W) x 1024 (H)
16.2M
Video Input
Video Output
Analog: 15-pin, D-sub connector x 1, BNC IN x1
BNC OUT x1
Power Supply
Input voltage:
Output rating:
100-240V /60-50Hz
12V DC, 4.2A
Power Consumption 50 watts (maximum), 3 watts (standby)
Audio 3 watts x 2 built-in speakers
Frequency Horizontal:30-82 KHz; Vertical: 50-75 Hz
Dimensions(set size) 16.7 (W) x 16.7 (H) x 6.9 (D) inch
[ 425 (W) x 425 (H) x 175 (D) mm]
Safety & EMI UL, CUL, FCC-B, CB, CE, TUV/GS
Weight N.W.: 12.1 lbs (5.5 Kg)
G.W.: 15.4 lbs (7.0 Kg)
Operating Conditions 5°C – 35°C; 20%-80% RH
Storage Conditions: -20°C – 60°C; 10%-90% RH
Wall mount VESA 75 bracket
