Configuring Monitor Link
Before configuring a Monitor Link group, you must create a Monitor Link group and configure member
ports for it. A Monitor Link group consists of an uplink port and one or multiple downlink ports. The uplink
port can be a manually-configured or static LACP link aggregation group, an Ethernet port, or a Smart
Link group. The downlink ports can be manually-configured link aggregation groups or static LACP link
aggregation groups, or Ethernet ports.
Configuration Task List
Complete the following tasks to configure Monitor Link:
Task Remarks
Creating a Monitor Link Group Required
Configuring the Uplink Port Required
Configuring a Downlink Port Required
Creating a Monitor Link Group
Follow these steps to create a Monitor Link group:
To do… Use the command… Remarks
Enter system view
system-view
—
Create a Monitor Link group
monitor-link group group-id
Required
Configuring the Uplink Port
Follow these steps to configure the uplink port:
To do… Use the command… Remarks
Enter system view
system-view
—
Enter the specified Monitor Link group view
monitor-link group group-id
—
