Connecting the parking brake cord

Connect the cord to parking brake lamp ground in the meter panel.

Note:

•ConnectingtheparkingbrakecordtolampgroundallowsyoutowatchiPod/iPhonevideo/DVDvideo/AVinputwhen

the parking brake is engaged.

•Whentheparkingbrakecordisnotconnected,themonitorwillnotshowanyvideosources.

•If“AUDIOONLY”appearsonthescreenjustafterturningontheACCpowerofthecar,releasetheparkingbrake

whileconrmingsafety,andthenengagetheparkingbrakeagain.

Connecting the accessories

•Connectingtotheexternalamplier

Theexternalamplierscanbeconnectedtothe6channelRCAoutputconnections.Ensurethattheconnectors

are not grounded or shorted to prevent damage to the unit.

•ConnectingtoiPod/iPhonedevice

TheiPod/iPhonedevicecanbeconnectedtodedicatediPod/iPhoneconnectiononthemainunit.Fordetailed

information,refertotheinstructionsheetormanualfortheiPod/iPhonecable.

Note:

•ThisunitmaynotsupportallfunctionsofalliPod/iPhonedevices.

•TheiPod/iPhoneconnectionwillchargeyouriPod/iPhoneunlesstheiPod/iPhonebatteryiscompletelydepleted.If

thespeciedcordofthecellularphoneisconnectedtothephoneinterruptcordofthemainunit,theaudiomuteis

activated when cellular phone in use.

•ConnectingtoSiriusXMRadioReceiver

WhenSiriusXMRadioReceiveristobeconnected,usethededicatedconnector.Fordetailedinformation,refer

totheinstructionmanualoftheSIriusXM-ConnectVehicleTuner.

Parkingbrakelamp

cord to battery

Electro-tap

Parkingbrake

signal cord

Parkingbrake

signal cord

Stopper

Parkingbrake

signal cord

Parkingbrake

Parkingbrakecord

(Grass-green)

Parkingbrakecord

(Grass-green)

Howtoattachtheelectro-tap

1.PlacetheParkingbrakecordatthestopper,and

fold it back in the direction of the arrow

2.PasstheParkingbrakesignalcordthrough,and

fold it back in the direction of the arrow.
