The Administrator Viewer window contains a menu bar and a toolbar from which you
can specify parameters for viewing the displayed source. The table below describes these
controls.
Administrator Viewer menu Options
Menu Option Toolbar Icon Description
Connection menu
Disconnect
Disconnects the Administrator software from the QGE
stream and closes the Viewer window.
View menu
Scale
Places the Viewer window in scale mode. In this
mode, the source image fills the display portion of
the window. To increase or decrease the size of the
image, drag the edges or corners of the window.
NOTE: The scaled image may take several seconds
to display.
Unity
Places the Viewer window in unity mode. In this
mode, the size of the source display remains constant,
whether or not the Viewer window is resized.
NOTE: If the source image is larger than the
available Viewer window space, selecting
Unity crops the visible image. Scroll bars
appear, allowing you to select the part of
the image to view.
Frame Rate
and Bandwidth
None Toggles between displaying and hiding the frame rate
and bandwidth for the selected source. (These items
appear on the bar at the bottom of the window.)
Toolbar
None Toggles between displaying and hiding the four
toolbar icons below the menu bar.
Full Screen
Fills the screen with the source image. To return to
normal viewing, press <Esc> or <Alt> + <Enter> on
the computer keyboard.
Tools menu
Mouse &
Keyboard
None Toggles mouse and keyboard control on and off (see
“Mouse and Keyboard Control of the Source
Computer” on page 41.
