Alpine CDE-124SXM Car Stereo System User Manual



13-EN
3
Turn the Rotary encoder to select the desired folder.
4
Press and hold ENTER for at least 2 seconds to play
back the first file in the selected folder.
Notes
•Press and hold for at least 2 seconds in the search mode to cancel.
Or, the search mode is canceled if no operation is performed for
60 seconds.
To search for files in the Folder Name Search mode, press ENTER.
Files in the folder may be searched.
•Press to exit Folder Name Search mode in step 3 in order to select
File Name Search mode.
The root folder is displayed as “\ROOT”.
When Folder Name Search is made during M.I.X. play, the M.I.X. play
mode will be canceled.
1
During MP3/WMA/AAC playback, press ENTER to
activate the search mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select File Name Search mode,
and then press ENTER.
3
Select the desired file by turning the Rotary encoder.
4
Press ENTER to play back the selected file.
Notes
•Press and hold for at least 2 seconds in the search mode to cancel.
Or, the search mode is canceled if no operation is performed for
60 seconds.
•Press in the search mode to return to the previous mode.
When File Name Search is made during M.I.X. play, the M.I.X. play
mode will be canceled.
Quick Search
You can search for tracks (files).
1
Press and hold ENTER for at least 2 seconds in the CD/
MP3/WMA/AAC mode to activate Quick Search mode.
The “” indicator lights up.
2
Turn the Rotary encoder to select a desired track (file),
and then press ENTER.
The selected track is played back immediately.
Note
•Press in the search mode to cancel. Or, the search mode is canceled
if no operation is performed for 10 seconds.
About MP3/WMA/AAC
CAUTION
Except for private use, duplicating audio data (including MP3/
WMA/AAC data) or distributing, transferring, or copying it,
whether for free or for a fee, without permission of the copyright
holder is strictly prohibited by the Copyright Act and by
international treaty.
What is MP3?
MP3, whose official name is “MPEG-1 Audio Layer 3,” is a compression
standard prescribed by the ISO, the International Standardization
Organization and MPEG which is a joint activity institution of the IEC.
MP3 files contain compressed audio data. MP3 encoding is capable of
compressing audio data at extremely high ratios, reducing the size of
music files to as much as one-tenth their original size. This is achieved
while still maintaining near CD quality. The MP3 format realizes such
high compression ratios by eliminating the sounds that are either
inaudible to the human ear or masked by other sounds.
What is WMA?
WMA, or “Windows Media™ Audio,” is compressed audio data.
WMA is similar to MP3 audio data and can achieve CD quality sound
with small file sizes.
What is AAC?
AAC is the abbreviation for “Advanced Audio Coding,” and is a basic
format of audio compression used by MPEG2 or MPEG4.
Method for creating MP3/WMA/AAC files
Audio data is compressed using software with MP3/WMA/AAC codecs.
For details on creating MP3/WMA/AAC files, refer to the user’s manual
for that software.
MP3/WMA/AAC files that are playable on this device have the file
extensions “mp3” / “wma” / “m4a”. Files with no extension cannot be
played back (WMA ver. 7.1, 8 and 9 are supported). Protected files are
not supported, neither are raw AAC files (using the “.aac” extension).
There are many different versions of the AAC format. Confirm that the
software being used conforms to the acceptable formats listed above.
It’s possible that the format may be unplayable even though the
extension is valid.
Playback of AAC files encoded by iTunes is supported.
Supported playback sampling rates and bit rates
MP3
WMA
AAC
This device may not play back correctly depending on sampling rates.
ID3 tags/WMA tags
This device supports ID3 tag v1 and v2, and WMA tag.
If tag data is in an MP3/WMA/AAC file, this device can display the title
(track title), artist name, and album name ID3 tag/WMA tag data.
This device can only display single-byte alphanumeric characters (up to
30 for ID3 tags and up to 15 for WMA tags) and the underscore. For
non-supported characters, “NO SUPPORT” is displayed.
If information contains characters other than ID3 tag information, the
audio file may not be played back.
The tag information may not be correctly displayed, depending on the
contents.
Producing MP3/WMA/AAC discs
MP3/WMA/AAC files are prepared, then written to a CD-R or CD-RW
using CD-R writing software. A disc can hold up to 510 files/folders
(including Root Folders), and the maximum number of folders is 255.
Playback may not be performed if a disc exceeds the limitations
described above.
Media supported
The media that this device can play back are CD-ROMs, CD-Rs, and
CD-RWs.
Corresponding File Systems
This device supports discs formatted with ISO9660 Level 1 or Level 2.
Under the ISO9660 standard, there are some restrictions to remember.
File Name Search mode
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, 16 kHz,
12 kHz, 11.025 kHz, 8 kHz
Bit rates: 8 - 320 kbps
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz
Bit rates: 48 - 192 kbps
Sampling rates: 48 kHz, 44.1 kHz, 32 kHz, 24 kHz, 22.05 kHz, 16 kHz,
12 kHz, 11.025 kHz, 8 kHz
Bit rates: 16 - 320 kbps
