ALPINE CDE-9850Ri 68-04123Z56-A (EN)
Specifications
FM TUNER SECTION
MW TUNER SECTION
LW TUNER SECTION
CD SECTION
PICKUP
GENERAL
CHASSIS SIZE
NOSEPIECE SIZE
• Due to continuous product improvement, specifications and design
are subject to change without notice.
CAUTION
Tuning Range 87.5 – 108.0 MHz
Mono Usable Sensitivity 0.7 µV
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
Tuning Range 531 – 1,602 kHz
Sensitivity (IEC Standard) 25.1 µV/28 dB
Tuning Range 153 – 281 kHz
Sensitivity (IEC Standard) 31.6 µV/30 dB
Frequency Response 5 – 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 105 dB
Channel Separation 85 dB (at 1 kHz)
Wave length 795 nm
Laser power CLASS I
Power Requirement 14.4 V DC
(11–16 V allowable)
Maximum Power Output 50 W × 4
Maximum Pre-Output Voltage 2 V/10k ohms
Bass +20/-14dB at 60Hz
Treble ±14dB at 10kHz
Weight 1.6 kg (3 lbs. 8 oz)
Width 178 mm (7")
Height 50 mm (2")
Depth 162 mm (6-3/8")
Width 170 mm (6-11/16")
Height 46 mm (1-13/16")
Depth 24 mm (15/16")
CLASS 1
LASER PRODUCT
(Bottom side of player)
