01GB05CDA-9854R.fm
ALPINE CDE-9850Ri 68-04123Z56-A (EN)
• Protective circuit is activated due to high temperature.
- The indication will disappear when the temperature returns to
normal operating range.
• No CD is inserted.
- Insert a CD.
• Although a disc is inserted, “NO DISC” is displayed and the unit
does not start to play or eject the disc.
- Remove the disc by following these steps:
Press the button again for at least 2 seconds.
If the disc still does not eject, consult your Alpine dealer.
• Mechanism error.
1) Press the button and eject the CD.
If not ejecting, consult your Alpine dealer.
2) When the error indication remains after ejecting, press the
button again.
If the error indication still does not turn off after pressing the
button for a few times, consult your Alpine dealer.
• When “ERROR” is displayed:
If that the disc cannot be ejected by pressing , press the RESET
switch (refer to page 7) and press again.
If the disc still cannot be ejected, consult your Alpine dealer.
• A copy-protected WMA file was played back.
- You can only play back non-copy-protected files.
• The disc is not written in a MP3/WMA supported format.
- Use a disc written at the MP3/WMA supported format.
• The iPod is not connected.
- Make sure the iPod is correctly connected (refer to
“Connections”).
Make sure the cable is not bent excessively.
• The iPod’s battery remains low.
- Refer to the iPod’s documentation and charge the battery.
• There are no songs in the iPod.
- Download songs to the iPod and connect to the adapter.
• Communication error
- Turn the ignition key off, and then set to ON again.
- Check the display by reconnecting between the iPod and the
adapter, using the iPod cable.
• Caused by the iPod Software Version not being compatible with
the unit.
- Update the iPod Software Version to be compatible with the
unit.
Indication for CD Player
Indication for iPod Mode
01GB00CDA-9854R.book Page 24 Wednesday, October 19, 2005 8:21 AM
