11
At all mode, press and hold [D] button to
enter system setup. Press [ ] or [ ] button
to select options, rotate the [VOLUME] knob
to adjust.
CLOCK
Press the [VOLUME] knob to enter clock
setting mode, Rotate the [VOLUME] knob to
set clock, press [ ] or [ ] button to select
hour or minute, press and hold the [VOLUME]
knob to conrm.
PASSWORD(SIRIUSmode)
Press the [VOLUME] knob to enter old
password, rotate the knob to select a digit,
press [ ] or [ ] button to move the
cursor. Long press the knob to conrm after
input all 4 digit. Then input a new 4-digit
number as above. (Original password: 0000)
LOCK(SIRIUSmode)
Press the [VOLUME] knob to lock current
station, rotate the knob to select a digit, press
[ ] or [ ] button to move the cursor.
Long press the knob to conrm after input all
4 digit password.
UNLOCK(SIRIUSmode)
Press the [VOLUME] knob to unlock all
locked stations, rotate the knob to select a
digit, press [ ] or [ ] button to move
the cursor. Long press the knob to confirm
after input all 4 digit password.
DX/LO(RADIOmode)
Rotate the [VOLUME] knob to choose radio
local or distant at RADIO mode.
• LO: Only stations with strong signal can
be received.
• DX: Stations with strong and weak signals
can be received.
AUXSENS(AUXmode)
Rotate the [VOLUME] knob to choose AUX
Input sensitivity LOW, MID or HIGH at AUX
mode.
PIN CODE
Rotate and press the [VOLUME] knob to
choose a 4-digit password. Press the knob
more than 1 second to conrm.
System Setup
SCRNSVR:ON/OFF
Rotate the [VOLUME] knob to choose SCRN
SVR (screen saver) ON or OFF.
SCROLL:ON/OFF
For track information that is longer than the
display panel:
When SCROLL is ON, the LCD will display
ID3 TAG information cyclely, e.g: TRACK-
>FOLDER->FILE->ALBUM->TITLE-
>ARTIST->TRACK->...
When SCROLL is OFF, the LCD will display
one of the ID3 TAG information, the default
is TRACK, but user can adjust it to other ID3
TAG information by press [DISP] button.
S-CTRL(IPODmode):ON/OFF
Rotate the [VOLUME] knob to choose S-CTRL
(Simple Control) ON or OFF.
* Refer to P20.
SW PHASE
Rotate the [VOLUME] knob to choose SUB-
WOOFER phase REVERSE or NORMAL.
DIMMER:ON/OFF
Rotate the [VOLUME] knob to choose
DIMMER ON or OFF.
• ON: LCD dimmer is active when small light
of vehicle is turned ON.
• OFF: LCD always maximum brightness
regardless of the vehicle small light.
BEEP:ON/OFF
Rotate the [VOLUME] knob to choose button
beep sound ON or OFF.
12/24H
Rotate the [VOLUME] knob to choose time
format: 12 or 24 hour.
MICSEL(BTmode)
Rotate the [VOLUME] knob to choose
Microphone EXTERNAL or INTERNAL.
MICGAIN(BTmode)
Rotate the [VOLUME] knob to choose Mic
gain: 1, 2, 3, 4, 5.
You can change the gain of MIC when a
telephone partner cannot hear your voice.
CMB1525194A(Z501) manual.indb 11 2010-11-26 15:51:02
