22
English
Bluetooth Operations
The Bluetooth allows you to utilize your car’s
built-in audio system for wireless mobile
phone or music handsfree communication.
Some Bluetooth mobile phones have the
audio features, and some portable audio
players support Bluetooth feature. This
system can play audio data stored in a
Bluetooth audio device. The car stereo with
Bluetooth will be able to retrieve phonebook
contacts, received call, dialled call, missed
call, incoming calls, outgoing call and listen
to music.
Note:
• Do not leave the microphone of Bluetooth
handsfree in the places with wind passing
such as air outlet of the air conditioner,
etc. This may cause a malfunction.
• If leave it in the places subjected to
direct sun, high temperature can cause
distortion, discoloration which may result
in a malfunction.
• This system will not operate or may
operate improperly with some Bluetooth
audio players.
• Clarion cannot guarantee the compatibility
of all mobile phones together with the unit.
• Audio playback will be set to the same
volume level as set during telephone call.
This might cause problems, if extreme
volume level is set during telephone call.
Handsfree Operations
Pairing
1. Turn on Bluetooth function of your mobile
phone.
2. Enter mobile phone’s Bluetooth setup
menu.
3. Search for new Bluetooth devices.
4. Select CZ501 from the pairing list on the
mobile phone.
5. Enter “0000” as the password.
6. After pairing successfully, the unit will
enter Bluetooth mode automatically, and
“BLUETOOTH CONNECTED” will appear
on the LCD.
Making a call
OperationfromBluetoothmenu
Press the [SRC / ] button to switch the
source to “BLUETOOTH”. Press [MENU /
]
button to select a way to make outgoing call:
•DialNumber
1. Press the [MENU /
] button.
2. Rotate the [VOLUME] knob on the front
panel to select "DIAL NUMBER".
3. Press the knob to enter the selected Dial
Number.
4. Rotate the [VOLUME] knob to select a
number, press the knob to confirm and
ready to input the next digit. Repeat the
above until all numbers inputted.
5. Press the [BAND / ] to dial.
6. Press [MENU / ] to terminate call.
•Dialled/Missed/ReceivedCallHistory
You can search any Dialled/Missed/Received
Call History.
1. Rotate the knob to select “DIALLED”,
“MISSED” or “RECEIVED”.
2. Press the knob to enter the selected call
history.
3. Rotate the knob or press the [ ] or [ ]
button on the remote control to scroll the
contacts.
4. When the contact name or mobile phone
No. is displayed, press the [BAND / ]
button to call the mobile phone No. of that
contact.
* Press the [MENU / ] button to end the
call.
•CallfromPhonebook
User can search the contact name in the
phonebook and make call.
1. Rotate the knob to select “SIM PHONE
BOOK” or “MEMORYPHONEBOOK“.
2. Press the [VOLUME] knob to enter the
selected phonebook.
3. Use the [ ] or [ ] button on the remote
control or rotate the [VOLUME] knob to
scroll the contacts.
4. When the contact name is displayed, press
the [BAND / ] button to call the mobile
CMB1525194A(Z501) manual.indb 22 2010-11-26 15:51:05
