English
22 DB185MP
Operations Common to Each Mode
● Setting the clock
2-1. Select “CLOCK”.
3-1. Press the [ ] button
3-2. Press the [x] or [v] button to select the
hour or the minute.
3-3. Turn the [ROTARY] knob to set the correct
time.
∗ The clock is displayed in 12-hour format.
3-4. Press the [ ] button to store the time into
memory and return to the previous mode.
Note:
• You cannot set the clock when it is displayed
with only the ignition on. If you drain or remove
the car’s battery or take out this unit, the clock is
reset. While setting the clock, if another button or
operation is selected, the clock set mode is
canceled.
● Displaying the settings
The number of indicator of this unit decreases,
you can see the state of current settings at any
operation mode.
2-1. Select “SETTINGS”.
3-1. Turn the [ROTARY] knob to display the
state of current settings.
∗ When the setting is selected, after 1 second
the current state will be displayed.
● Turning the screen saver function on
or off
This unit is provided with the screen saver
function which allows you to show various kinds
of patterns and characters in the operation
status indication area of the display in a random
order. You can turn on or off this function. If the
button operation is performed with the screen
saver function on, the operation display
corresponding to the button operation is shown
for about 30 seconds and the display returns to
the screen saver display.
∗ The factory default setting is “ON”.
2-1. Select “SCRN SVR”.
3-1. Turn the [ROTARY] knob to select “ON” or
“OFF”.
To change adjustment setting
1. Press and hold the [DISP] button for 1
second or longer to switch to the
adjustment selection display.
2. Press the [x] or [v] button to select
the “item name”.
“CLOCK” ↔ “SETTINGS” ↔ “SCRN SVR”
↔ “SCROLL” ↔ “DIMMER” ↔ “TEL-SP”
↔ “TEL-SW”
∗ The adjustment item name will be displayed
for 2 seconds before showing the desired
value.
3. Turn the [ROTARY] knob to select the
“desired setting value”.
∗ In the case of display blinking “ENT”, you
can press the [ ] button to adjust the
setting value.
∗ After completing settings, press the [DISP]
button to return to the previous mode.
or
For example: after 1 second,
