36 VRX630
English
Owner’s manual
Note:
• If the VSE effect is set to OFF, the adjustment made
in “VSE operations” is not reflected in the music
source.
Calling VSE BASIC Pattern/USER
Pattern
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “VSE MODE”. “BASIC” and
“USER” items are displayed in the menu bar.
3. Operate the JOYSTICK ¡ rightward or left-
ward to select the item thus called, and press
the ENT at the center of the JOYSTICK ¡ to
show BASIC pattern selecting display or
USER pattern selection/memory display.
4. In the pattern selecting display, operate the
JOYSTICK ¡ rightward or leftward to select
P1 to P6, and press the ENT at the center of
the JOYSTICK ¡ to call corresponding VSE
pattern. In this display, pressing the No. but-
ton in correspondence to the Preset buttons
# can also call the VSE pattern.
∗ After selecting P1 to P6 by operating the JOY-
STICK ¡ rightward or leftward, press the ENT
at the center of the JOYSTICK ¡ for 2 sec-
onds or longer to copy the selected pattern to
the USER pattern.
∗ Operate the JOYSTICK ¡ rightward or left-
ward to select “EDIT”, and press the ENT at
the center of the JOYSTICK ¡ to show the
VSE adjusting display, in which the properties
of currently selected pattern can be adjusted.
∗ By pressing the BND button % in BASIC pat-
tern selecting display or USER pattern selec-
tion/memory display you can switch between
the two patterns, BASIC and USER.
5. Operate the JOYSTICK ¡ rightward or left-
ward to select “MENU”, and press the ENT at
the center of the JOYSTICK ¡ to return to
the AUDIO-MODE display.
Setting and storing VSE Properties/
Memory into USER Pattern
1. Repeat the steps 1 to 3 of the previous pro-
cedure (Calling VSE BASIC Pattern/USER
Pattern) to show BASIC pattern selecting
display or USER pattern selection/memory
display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “VSE EDIT”, and press the
ENT at the center of the JOYSTICK ¡ to
show the VSE adjusting display.
3. Select an item to be adjusted by operating
the JOYSTICK ¡ rightward or leftward in the
VSE adjusting display.
“DIFF” ➜ DIFFUSE
“C.WD” ➜ CAR WIDTHH
“C.LG” ➜ CAR LENGTH
4. Operate the JOYSTICK ¡ upward or down-
ward to set each adjusting value.
∗ By pressing the preset buttons # once in the
VSE adjusting display, the setting value for
currently stored USER pattern is obtained.
5. After making adjustments to a desired pat-
tern by repeating the steps 3 and 4, operate
the JOYSTICK ¡ rightward or leftward to
move the cursor to “RTN”, and press the
ENT at the center of the JOYSTICK ¡ to
change over to the BASIC/USER pattern se-
lection/memory display.
6. Operate the JOYSTICK ¡ rightward or left-
ward in the BASIC/USER pattern selection/
memory display to select USER memory P1
to P6 to be stored, and press the ENT at the
center of the JOYSTICK ¡ for 2 seconds or
longer to store the adjusted VSE pattern to
the USER memory.
∗ By pressing the preset buttons # 1 to 6 for 2
seconds or longer in the VSE adjusting dis-
play, the VSE pattern can be stored in the
USER memory.
7. To set a title of the stored USER pattern, op-
erate the JOYSTICK ¡ rightward or leftward
to select “TITLE” and press the ENT at the
center of the JOYSTICK ¡ to change into
the Title Input display.
∗ For title inputting method, refer to the section
“Entering titles”.
8. Operate the JOYSTICK ¡ rightward or left-
ward to select “MENU” and press the ENT at
the center of the JOYSTICK ¡ to change
into the AUDIO-MODE display.
Professional mode/P.EQ
operations
P.EQ effect ON/OFF
∗ The factory default setting is “ON”.
1. Press the A-M button & to show the AUDIO-
MODE display.
2. Operate the JOYSTICK ¡ upward or down-
ward to select “P.EQ ON/OFF”, “ON” and
“OFF” items are displayed in the menu bar.
DSP operations
