OOppeerraattiinngg tthhee MMoonniittoorr
OOPPEENN//CCLLOOSSEE TTHHEE DDIISSPPLLAAYY MMOONNIITTOORR
To open the display monitor, push the "OPEN" button and pull the monitor down
bbyy tthhee mmiiddddllee
of the
LCD to the desired position. Use the
mmiiddddllee ooff tthhee
LCD screen to rotate to a desired viewing position.
WWAARRNNIINNGG::
THE LCD MONITOR MUST ALWAYS BE OPENED, CLOSED, OR POSITIONED FROM
THE MIDDLE OF THE SCREEN AS SHOWN BY THE POINTING HAND BELOW. DO
NNOOTT
USE THE
CORNERS OF THE SCREEN, THIS CAN RESULT IN DAMAGE/LEAKAGE OF THE SCREEN.
WWAARRNNIINNGG::
DO NOT CLOSE THE LCD SCREEN IF A MEMORY CARD HAS BEEN INSERTED INTO
THE DVD PLAYER. THIS CAN CAUSE THE LCD SCREEN TO BREAK OR LEAK FLUID. IF YOU
SHOULD COME IN CONTACT WITH LEAKED FLUID, WASH THE AFFECTED AREA THOROUGHLY
WITH WATER AND SEEK IMMEDIATE MEDICAL ATTENTION. REMOVE ALL MEMORY CARDS
BEFORE CLOSING THE LCD SCREEN.
To close the display monitor, first rotate the LCD screen to align for closure and then push the LCD
screen up until it latches closed with an audible click.
NNoottee::
The ignition key must be in the Accessory or Ignition position in order for
the monitor to have power.
Closed Position
Open Button
Open Position
Use this portion of the
screen for opening, closing,
and positioning.
20
