FINE TUNING THE HIGH-PASS CROSSOVER HIGH RANGE
The crossover section is marked at four frequency points for
ease of system adjustment. These points are 10 Hz, 35 Hz , 120
Hz and 1 kHz. Specific crossover points can be to be chosen
based on the recommended operational bandwidth of your
speakers.
Note: When the high-pass crossover is set in the HIGH fre-
quency range, the corner frequencies are 100 Hz, 350 Hz,
1.2 kHz and 10 kHz respectively.
