Orion Car Audio XTREME 300 Car Stereo System User Manual



page 51
SYMPTOM PROBABLE CAUSE ACTION TO TAKE
Distorted output Speaker not connected to properly Check speaker wiring and fix or replace as needed. Refer to the amplifier
continued... speaker connections section of this manual for detailed instructions
Internal crossover not set properly Readjust crossovers. Refer to the internal crossover section of this
for speakers manual for detailed instructions
Speakers are blown Check system with know working speakers and fix or replaceas needed
Poor bass response Speakers wired with wrong Check speaker polarity and fix as needed
polarity causing cancellation at low frequency
Crossover set incorrectly Reset crossovers. Refer to the internal crossover
section of this manual for detailed instructions
Impedance load at amplifier Check speaker impedance load, if below 2 stereo or 4 mono
is too low. Rewire speakers to achieve a higher impedance
Battery fuse blowing Short in power wire or incorrect Check power and ground connections and fix or repair as needed
power connections.
Fuse used is smaller than Replace with proper fuse size
recommended
Too much current being drawn Check speaker impedance load, if below 2 stereo or 4 mono
rewire speakers to achieve a high impedance
Check power and ground connections and fix or repair as needed
Amplifier fuse Too much current being drawn Check speaker impedance load, if below 2 stereo or 4 mono
blowing rewire speakers to achieve a high impedance and replace with
recommended size fuse
Check power and ground connections and fix or repair as needed
Fuse used is smaller than Replace with proper fuse size
recommended
Impedance load at amplifier Check speaker impedance load, if below 2 stereo or 4 mono
too low. Rewire speakers to achieve a higher impedance
Speaker is blown with shorted Check system with know working speakers and fix or replace
outputs as needed
