Carbattery

Figure 1

25

9. INSTALLATION/WIRE CONNECTION

GUIDE

1.Thissetisexclusivelyforuseincarswitha

negativeground12Vpowersupply.

2. Read these instructions carefully.

3.Besuretodisconnectthebatteryterminalbefore

starting. This is to prevent short circuits during

installation.(Figure1)

2) Package Contents

3) General Cautions

1. Do not open the case. There are no

user-serviceablepartsinside.Ifyou

drop anything into the unit during

installation, consult your dealer or an

authorizedClarionservicecenter.

CONTENTS

1)BeforeStarting ....................................................................... 25

2)PackageContents ................................................................. 25

3)GeneralCautions ................................................................... 25

4)CautionsonInstallation .......................................................... 26

5)InstallingtheSourceUnit ....................................................... 26

6)RemovingtheSourceUnit ..................................................... 28

7)WiringandConnections ......................................................... 29

8)ConnectingtheAccessories .................................................. 30

Source unit ...........................................1

Front panel ...........................................1

Trim ring ...............................................1

Mountingbracket .................................1

ScrewM5x6mm ..................................4

L-key ....................................................2

Wire connector .................................... 1

Remotecontrolunit(withbattery) ........1

Owner’smanual ...................................1

Warranty card ...................................... 1

Microphone .......................................... 1

DCP case.............................................1

1) Before Starting

2. Use a soft, dry cloth to clean the case.

Never use a rough cloth, thinner,

benzine,oralcohol.Fortoughdirt,

applyalittlecoldorwarmwatertoa

softclothandwipeothedirtgently.
