Mountingbracket

Dashboard

Screwdriver

27

Notes on installation

1. Before installation, please make sure that

allconnectionshavebeenproperlymade

andtheunitoperatesnormally.Improper

connection may result in damage to the

unit.

2. Use only accessories designed and

manufactured for this unit. The use of other

unauthorizedaccessoriesmayresultin

damage to the unit.

3. Beforeinstallation,pleasefastenallpower

cables.

4. DONOTinstalltheunitwhereitwillbe

exposed to heat to prevent damage to

electrical components such as the laser

head.

5. Installtheunithorizontally.Installingthe

unit more than 30 degree vertically may

result in degraded performance.

6. To prevent electric spark, connect the

positivepolerstandthenthenegative

pole.

7. DONOTblockthecoolingfanexitto

ensuresucientheatingdissipationofthis

unit, or it may result in damage to this unit.

Unit installation

Method A

1. Insertmountingbracketintodash

board,chooseappropriatemountingtab

accordingtothegapwidth,bendingthe

mountingtaboutwardswithascrewdriver

toxthemountingbracketinplace.

2. Slidetheunitintothebracketuntilyouhear

a click sound.
