BBus Module
CHAPTER 4
This chapter describes the BBus module, which provides the data path between
NS7520 internal modules. Additional BBus functionality includes:
Address and multiplexing logic that supports the data flow through the
NS7520.
Central arbiter for all NS7520 bus masters.
Internal register decoding for all addressable modules.
