8-EN
This unit cannot receive HD Radio signals (digital terrestrial radio). In
order to activate the digital radio functions described below, an optional
HD Radio Tuner module must be connected through the Ai-NET bus.
iTunes Tagging lets you tag songs you hear on HD Radio stations with
your new iDA-X303 and then preview, buy, and download them later
from your iTunes Tagged playlist the next time you sync your iPod.
If the unit is connected to a Tagging compatible device, you can use the
iTunes Tagging function. For details, refer to the Owner’s Manual of the
Tagging compatible device.
Listening to Radio
HD Radio signals can be received if the HD Radio TUNER MODULE
(TUA-T500HD) is connected. While receiving HD Radio signals, the
unit can automatically switch between the analog and digital signal.
1
Press SOURCE to select TUNER mode.
2
Press BAND repeatedly until the desired radio band
is displayed.
FM1 FM2 AM FM1
3
Press TUNE/A.ME to select the tuning mode.
DX SEEK (Distance mode) SEEK (Local mode)
(Blank) (Manual mode) DX SEEK (Distance mode)
• The initial mode is Distance mode.
Distance mode:
Both strong and weak stations will be automatically tuned in
(Automatic Seek Tuning).
Local mode:
Only strong stations will be automatically tuned in (Automatic
Seek Tuning).
Manual mode:
The frequency is manually tuned in steps (Manual tuning).
4
Press or to tune in the desired station.
Holding down or will change the frequency
continuously.
• When DIGITAL SEEK is ON, SEEK UP/DOWN only stops on digital
broadcasts with the HD Radio connected. Refer to “Digital Seek On/
Off Setting” (page 23).
Presetting Stations Manually
1
Select the radio band and tune in a desired radio
station you wish to store in the preset memory.
2
Press PRESET.
The Preset screen is displayed.
3
Turn the Double Action encoder to select the
preset number.
4
Press and hold
/
ENTER for at least 2 seconds.
The selected station is stored.
The display shows the band, preset number and station
frequency memorized.
• A total of 18 stations can be stored in the preset memory (6 stations
for each band; FM1, FM2 and AM).
• If you store a station in a preset memory which already has a station,
the current station will be cleared and replaced with the new station.
Presetting Stations Automatically
1
Press BAND repeatedly until the desired radio band
is displayed.
2
Press and hold TUNE/A.ME for at least 2 seconds.
The tuner will automatically seek and store 6 strong stations
in the selected band. They will be stored 1 to 6 in order of
signal strength.
When the automatic memory has been completed, the tuner
goes to the station stored in preset location No.1.
• If no stations are stored, the tuner will return to the original station
you were listening to before the auto memory procedure began.
Tuning to Preset Stations
1
Press BAND repeatedly until the desired band is
displayed.
2
Press PRESET.
The Preset screen is displayed.
3
Turn the Double Action encoder to select a radio
station.
4
Press
/
ENTER.
The display shows the band, preset number and frequency
of the station selected.
Radio
TUNE/A.ME
/ENTER
PRESET
Double Action encoder
VIEW
SOURCE
FUNCTION/SETUP
BAND
