21-EN
DISPLAY:
DIMMER
SCROLL TYPE
TEXT SCROLL
DIMMER
IPOD:
PLAYLISTS
ARTISTS
ALBUMS
PODCASTS
AUDIOBOOKS
GENRES
COMPOSERS
SONGS
PLAYLISTS
TUNER:
XM ADF*
13
GAME ALERT*
13
STATION CALL*
14
DIGITAL SEEK*
14
XM ADF*
13
*
4
If IMPRINT audio processor is connected, you can make more
detailed settings for the audio setting. For details, refer to
“IMPRINT Operation (Optional)” (page 29).
*
5
Displayed only when an external audio processor is connected.
*
6
Displayed only when MX is set to ON and an external audio
processor is connected.
*
7
Refer to “Setting the Calendar” (page 7).
*
8
Refer to “Setting the Time” (page 7).
*
9
Displayed only when BT IN is OFF.
*
10
The setting can be made only when AUX+/AUX is set to ON.
*
11
Displayed only when DIGITAL AUX is set to ON.
*
12
Displayed only when AUX+ is set to ON.
*
13
Displayed only when SAT radio receiver is connected.
For the SAT Radio Setting, refer to “SAT Radio Receiver
(Optional)” (page 24).
*
14
Displayed only when HD Radio TUNER MODULE (TUA-T500 HD)
is connected.
4
Turn the Double Action encoder to change the
setting, and then press
/ENTER.
(e.g. Select POWER IC ON or POWER IC OFF.)
5
Press and hold for 2 seconds to return to normal
mode.
Pressing during the procedure will return to the previous mode.
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Select BT from the setup main menu in step 2 above.
If an optional Bluetooth INTERFACE (KCE-400BT) is connected, you
can place a hands-free call by a Bluetooth-equipped mobile phone.
Make this setting when the Bluetooth INTERFACE (KCE-400BT) is
connected and the Bluetooth function is used. For details, refer to the
Owner’s Manual of the optional Bluetooth INTERFACE
(KCE-400BT).
Set ADPT when the Bluetooth INTERFACE (KCE-400BT) is
connected.
The button can be used only when the optional Bluetooth
INTERFACE (KCE-400BT) is connected.
If the mobile phone compatible with the Voice Dial function is
connected, the Voice Dial function can be used.
When INT MUTE is set to ON, the Bluetooth setting cannot be made.
When the
Bluetooth INTERFACE
(KCE-400BT) is connected, set INT
MUTE to OFF. Refer to
“Turning Mute Mode On/Off (INT MUTE)”
(page 22).
Setting the Bluetooth Connection
AUDIO is selected on the setup menu in step 2.
Operating the External Audio Processor (USER PRESET)
Turn the Double Action encoder to select the desired preset number,
and then press
/ENTER.
In normal mode, you can also call up the preset memory of the external
audio processor by pressing and holding “PRESET” for at least 2
seconds. Refer to
“Operating the External Audio Processor” on page 20.
For the operation of external audio processor, refer to the Owner’s
Manual of the external audio processor you purchased.
Turning Media Xpander ON/OFF
When the Media Xpander is on, and external audio processor is
connected, you can adjust the Media Xpander level.
Setting the MX Level
MX (Media Xpander) makes vocals or instruments sound distinct
regardless of the music source. The FM radio, CD, USB memory and
iPhone/iPod, will be able to reproduce the music clearly even in cars
with a lot of road noise. The initial setting is different depending on the
source.
Subwoofer On and Off
The adjustment can also be made by pressing and holding IMPRINT*
for at least 2 seconds. Refer to
“Turning Subwoofer ON/OFF”
(page 18).
* For this unit, when connecting IMPRINT audio processor, you can’t
turn the subwoofer ON or OFF by pressing IMPRINT.
Bluetooth Setting
BT IN ADPT / BT IN OFF (Initial setting)
Audio Setting (Only when external audio
processor is connected)
PRE-1 (Initial setting) / PRE-2 / PRE-3 / PRE-4 / PRE-5 / PRE-6
OFF (Initial setting) / ON
NON EFFECT / LEVEL 1 / LEVEL 2 / LEVEL 3
SUBW ON (Initial setting) / SUBW OFF
