20-EN
Pairing a BLUETOOTH compatible device with
SSP (Secure Simple Pairing)
1
Using your BLUETOOTH compatible device, select the
“Alpine CD Receiver” for pairing.
2
Turn the Rotary encoder to change the head unit display
from “PAIR NO” to “PAIR YES”.
If “PAIR NO” is selected, the connection will be canceled.
3
If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Pairing a BLUETOOTH compatible device without
SSP (Secure Simple Pairing)
1
Using your BLUETOOTH compatible device, select the
Alpine CD Receiver for pairing.
2
Input the PIN code (“0000”) in a BLUETOOTH compatible
device.
Note
• The PIN code is fixed as “0000”.
3
If the pairing was successful, “CONNECTED” is displayed
for a few seconds. The head unit then returns to its
previous state.
Notes
• If the connection is unsuccessful, “FAILED” is displayed.
• After a successful pairing, the two devices should re-pair automatically
whenever the vehicle’s ignition is turned ON.
• Set “VISIBLE M” to VISI M ON to enable this unit to be recognized by
a BLUETOOTH compatible device, refer to “Setting the Visible Mode”
on page 21.
• You can also manually pair the BLUETOOTH devices from this unit.
For details, refer to “Pairing a BLUETOOTH Device from the unit” on
page21.
BLUETOOTH SETUP
The following steps 1 to 5 are common to the various BLUETOOTH
functions. For details, refer to each individual function.
Note
• Set “HFP” or “AUDIO” to ON, and then perform BLUETOOTH
SETUP operation. Refer to “Setting the BLUETOOTH Connection
(BT IN)” on page 20.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2
Turn the Rotary encoder to select “BLUETOOTH”, and then
press ENTER.
The BLUETOOTH setup mode is activated.
Note
• The BLUETOOTH setup mode can also be activated by pressing and
holding w for at least 2 seconds.
3
Turn the Rotary encoder to select the desired items and
then press ENTER.
BLUETOOTH:
BT IN
*1
PAIRED DEV VISIBLE M
*1
SEARCH DEV
*1
CALL SOUND
*2
SENDER ID
*2
PB UPDATE
*2
PB ORDER
*2
AUTO ANS
*2
SEV NAME
*2
SPEAKER SL
*2
FW VERSION FW UPDATE
*1
*1 The items are not displayed during a phone call.
*2 The items are not displayed when “HFP” is set to OFF. Refer
to “Setting the BLUETOOTH Connection (BT IN)” on
page20.
4
Turn the Rotary encoder to change the settings.
5
Press and hold AUDIOSETUP for at least 2 seconds.
The SETUP mode is canceled.
Notes
•Press to return to the previous mode.
• Pressing and holding for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
With BLUETOOTH technology, you can place a hands-free call by a
BLUETOOTH-equipped mobile phone.
Audio information of a BLUETOOTH compatible mobile phone, a
portable audio player, etc., is controllable/playable wirelessly from this
unit.
Setting item: BT IN
Further setting items: HFP / AUDIO
Setting contents:
OFF / ON (Initial setting)
Hands-Free Phone setting (HFP)
ON:
Select when you want to pair your BLUETOOTH compatible phone
with this unit.
OFF:
Hands-Free Phone function is not used.
Note
• When HFP is set to OFF, the indicators related to Hands-free phone
(c battery quantity, i signal strength and h message) will not
be displayed.
BLUETOOTH Audio setting (AUDIO)
ON:
Select when you want to use BLUETOOTH Audio function.
OFF:
BLUETOOTH Audio function is not used.
Select one of 3 connected BLUETOOTH compatible devices that you
previously registered.
Setting item: PAIRED DEV
1
Turn the Rotary encoder to select a BLUETOOTH
compatible device you want to use (you want to change
connection) and then press ENTER.
Setting the BLUETOOTH Connection
(BT IN)
Setting the BLUETOOTH Device
