25-EN
1
Press any one of the preset buttons (1 through 6) that has
had a number stored in the phone mode.
The information (name/number) stored in the preset station is
displayed.
2
Press ENTER or f.
The stored preset number is dialed directly.
While calling, you can adjust the volume.
Turn the Rotary encoder to adjust the volume.
Note
• You may need to increase volume from your regular audio listening
source level. However, increasing the volume excessively may result in
feedback. Feedback is directly related to the volume. Turning down the
volume as low as acceptable, will reduce it. Positioning the microphone
in a direction away from the main car speakers (e.g. clipped on sun
visor) may also reduce feedback at high volume.
While calling, activating the Voice Mute function will instantly mute the
microphone input. Your voice will not be heard by the caller.
While calling, press to mute the microphone input.
Press again will bring the microphone input back to its
previous volume level.
Note
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 17.
While making a call, this function allows you to initiate the transfer of
the audio between the mobile phone and the speakers in the car.
While calling, press BAND to switch the call sound
between the unit and mobile phone.
Notes
• Depending on the mobile phone, this operation may not be performed.
• The operation can also be performed in the option menu of phone mode
(calling mode). Refer to “Option Menu Setting” on page 17.
BLUETOOTH Audio Operation
Audio information of a BLUETOOTH compatible mobile phone, a
portable player, etc., is controllable/playable wirelessly
*
from this unit.
* To play back audio, a mobile phone or a portable player conforming to
A2DP (Advanced Audio Distribution Profile) and AVRCP (Audio/
Video Remote Control Profile) is required.
Not all functions work with all devices.
Notes
• Set “AUDIO” to ON when you want to use BLUETOOTH Audio
function. Refer to “Setting the BLUETOOTH Connection (BT IN)” on
page20.
• During a call, sound on the BLUETOOTH audio source is muted.
• If you operate the Hands-free phone (e.g. searching in the phonebook)
while using the BLUETOOTH Audio function, BLUETOOTH Audio
playback may be affected.
Press SOURCE/ to select the BT AUDIO mode.
Press .
Return the beginning of the song being played back.
Press .
Forward the next song.
Press .
A playback stops. Touching again will resume a playback.
Dialing the preset number
Adjusting the volume when receiving a
Call
Muting the microphone input quickly
(Voice Mute)
Call Switching Operation
Recalling the BLUETOOTH Audio Mode
Selecting the desired Song
Pausing
