4-EN
Opening the Front Panel
1 Press the Open button on the Front Panel.
NOTE
Hide the Front Panel if it does not come out within 6
seconds after the Open button has been pressed.
The power will turn off after the Front Panel hiding.
Hiding the Front Panel
1 Press the HIDE button on the Front Panel for at
least 3 seconds.
NOTES
• The Front Panel will stop moving if there is an
obstacle inside the compartment. In that case, remove
the obstacle and press the HIDE button again for at
least 3 seconds.
• The power will turn off after the Front panel hiding.
Connectable to Remote Control Interface Box
You can operate this unit from the vehicle's control
unit when an Alpine Remote Control Interface Box
(optional) is connected. For details, contact your
Alpine dealer.
Basic Operation
Open Button
F1 F2FDN g f UP
Initial System Start-Up
1 Immediately after installing or applying power to
the unit, it should be initialized. Press the RESET
switch with a ballpoint pen or any other pointed
object.
NOTE
This should be operated when the front panel is hidden.
NOTE
The RESET switch is also on the front panel (to the right
of the TITLE button).
Turning Power On and Off
1 Press the PWR (Power) button to turn on the
unit.
NOTE
The unit can be turned on by pressing any other button
except the eject c button.
The volume level gradually increases to the previous
level you were listening to before the unit was turned
off. Press the PWR button for at least 3 seconds to
turn off the unit.
NOTE
The very first time the power is turned on, the volume
will start from level 12 in the tuner mode.
TUNE
Audio Control
INTLZ
PWR
MODE
RESET switch
c/HIDE
