67
Specifications
Signal system.................................... NTSC/PAL
Horizontal resolution ......................... 500 lines or greater
Video output level.............................. 1Vp-p (75 ohms)
Video S/N ratio .................................. DVD: 60 dB
Audio S/N ratio .................................. DVD: 95 dB
CD: 93 dB
Frequency response ......................... DVD: 5 Hz to 22 kHz (±1 dB) (48 kHz sampling)
DVD: 5 Hz to 44 kHz (±1 dB) (96 kHz sampling)
CD: 5 Hz to 20 kHz (±1 dB)
Dynamic range .................................. DVD: 90 dB or greater
CD: 93 dB or greater
Wow & flutter ..................................... Below measurable limit
Channel separation ........................... 80 dB
Harmonic distortion ........................... 0.03%
Audio output ...................................... 800 mV
Power supply .................................... DC 14.4V (operating range: 11 to 16V)
Operating temperature range ............ –10° to +60°C
Weight ............................................... 1.6 kg (3 lbs. 8 oz)
External dimensions (W x H x D) ...... 178 x 50 x 185 mm (7” x 2” x 7-1/4”)
• For improvement purposes, specifications and design are subject to change without
notice.
• The illustrations in this manual may appear different from the actual product due to
printing conditions.
