Basic Operations
English
11 CX201
3-1. Each time you turn the [ROTARY] knob to
select the setting, the setting changes in
the following order:
“THROUGH” ↔ “60” ↔ “90” ↔ “120”
∗ The factory default setting is “THROUGH”.
●Adjusting the subwoofer output
volume
You can adjust the volume output from the unit’s
subwoofer output terminal.
This adjustment can be performed only when
the “REAR/S-W” is set to “S-WOOFER”.
2-1. Select “S-W VOL”.
3-1. Turn the [ROTARY] knob to increase or
decrease the subwoofer volume.
∗ The factory default setting is “0”.
(Adjustment range: +6 to –6)
●Setting the phase
This set can be performed only when the
“REAR/S-W” is set to “S-WOOFER”.
2-1. Select “PHASE”.
3-1. Turn the [ROTARY] knob to select as
following order:
“NORMAL” ↔ “REVERSE”
∗ The factory default setting is “NORMAL”.
●Adjusting the high pass filter
2-1. Select “HPF”.
3-1. Each time you turn the [ROTARY] knob to
select the setting, the setting changes in
the following order:
“THROUGH” ↔ “60” ↔ “90” ↔ “120”
∗ The factory default setting is “THROUGH”
(through).
Note:
• During SOUND adjustment mode, if no operation
is performed for more than 10 seconds, this
mode can be cancelled and return to previous
mode.
