SIRIUS Satellite Radio Operations
English
14 CX201
Receiving stations selected by
category
Satellite Radio allows you to select broadcast
channel category (contents).
1. Press and hold the [BAND] button (1 sec.) to
select the category selection mode.
∗ It press and hold once again, return to the
channel selection mode.
2. Turn the [ROTARY] knob to change the
category item.
3. Press the [x] or [v] button to tune in a
station.
∗ If press and hold the [x] or [v] button, it
will quick tune a channel in the current
category.
∗ If turn the [
ROTARY] knob, it will tune the first
channel in the next or last category.
Notes:
• When the category selection mode is entered,
the category of the last received channel is
displayed first.
• If no operation is performed within 10 seconds,
the category selection mode is canceled, and
resumes to the channel mode.
Presetting a category
A category can be preset by registering specific
categories in [DIRECT] buttons 1 to 6. Then the
desired category can be recalled by pressing
the corresponding [DIRECT] button.
1. Press and hold the [BAND] button (1 sec.) to
enter the category mode.
2. Turn the [ROTARY] knob to select a
category.
3. Press and hold one of the [DIRECT] buttons
for 2 seconds or longer to store the current
category into preset memory.
Notes:
• When the name of a channel stored in memory is
changed by a broadcasting channel, the display
may show a channel name that differs from the
stored name.
• A channel stored in memory may be
discontinued at the option of the broadcasting
channel.
• If no operation is performed for more than 1
second, category seek tuning can automatically
tune in a receivable broadcast channel category.
Scan function
There are two scan modes: the category scan
mode and the preset scan mode.
During scanning channels are displayed in
abbreviated form, the display mode cannot be
switched.
● Preset scan (PRESET SCN)
A preset scan scans the channels (up to 18
channels) stored in the preset memory about
every 10 seconds.
∗ This function is available in the channel selection
mode.
Press the [ ] button. And start the preset
scanning.
● Category scan (CAT SCN)
In a category scan, broadcast channels in the
same category as the current channel are
selected about every 10 seconds.
∗ This function is available in the category selection
mode.
Press the [ ] button. And start the category
scanning.
Note:
• Category scanning is not available when no
category is defined for the current channel.
Parental Lock function
This function allows you to set a listening
limitation level.
This setting is possible only when a password is
entered.
● Setting the Password
∗ The factory default setting is “0000”.
1. Press and hold the [DISP] button.
2. Press the [x] or [v] button to select
“PARENTAL PASSWORD”.
3. Press the [ROTARY] knob.
4. Input the old password.
4-1. Press the [x] or [v] button to move
the cursor.
4-2. Turn the [
ROTARY] knob to select a
number.
4-3. Press and hold the [
ROTARY] knob.
5. Input a new password.
Repeat step 4-1 to 4-3.
6. Input the new password again.
Repeat step 4-1 to 4-3.
