13 CX201
SIRIUS Satellite Radio Operations
This function is available when this unit is
connected to the SCC1, SiriusConnect Vehicle
Tuner, (sold separately) with the SIRIUS SSP
cable.
Selecting a Satellite Radio mode
1. Press the [SOURCE] button.
The system changes to the specified
Satellite Radio mode.
Selecting a band
1. Press the [BAND] button to select a band.
This changes the reception band as follows:
SR1 ➜ SR2 ➜ SR3...
● Information displayed during reception
The following information is displayed when the
satellite radio cannot be received normally.
• W hen the tuner is not being connected: “NO
TUNER”.
∗ In this time, please turn off the power and
connect the tuner to this unit.
• W hen the antenna is not being received:
“ANTENNA ERROR”.
• W hen no signal is received: “NO SIG”.
• W hen the contract of the channel is being
updated: “SUB UPDT”.
• W hen the channel map is being updated:
“UPDATING”.
• A channel without a broadcast has been
selected: “INVALID CH”.
• A channel not covered by your contract:
“UNSUB CH” (alternated)
• W hen simulate firmware update: “F/W
UPDATE”.
Confirming your SIRIUS ID
1. Switch to channel 0.
∗ For details, see the following operation
descriptions.
2. The SIRIUS ID appears in the display.
Displaying channel labels
1. Press the [DISP] button to select the desired
channel label.
Channel ➜ Category ➜ Title (Artist) ➜
Composer ➜ Channel...
Channel input directly
This function allows you to input the channel No.
directly.
1. Press and hold the [DISP] button.
2. Press the [x] or [v] button to select
“DIRECT”.
3. Press the [ROTARY] knob.
4. Press the [x] or [v] button to move the
cursor.
5. Turn the [ROTARY] knob to select a number.
6. Press and hold the [ROTARY] knob.
Notes:
• If no operation is performed within 10 seconds, it
will return to the previous mode.
• If you select the Parental Locked channel, the
“CH LCKED” will appear in the display for 2 sec.
Then it will remind you to enter the password (For
details, see the chapter “Parental Lock
function” (page 14)).
Channel selection
1. Channels are selected with the [x] or
[v] button.
∗ For details, see the following operation
descriptions.
Notes:
• The audio output is muted and other button
operations are not accepted during channel
selection.
• The Parental Locked, unsubscribed and invalid
channels will be skipped and can not be tuned.
Recalling a preset station
A total of 18 satellite radio stations can be
stored.
6-SR1, 6-SR2 and 6-SR3
This allows you to store your favorite satellite
radio stations in memory for later recall.
1. Press the [BAND] button to select the
desired band.
2. Turn the [ROTARY] knob to select the
desired preset station.
Preset memory
1. Press the [BAND] button to select the
desired band.
2. Select the desired channel.
3. Press and hold the [DIRECT] button (2 sec.)
to store the current channel into preset
memory.
