21 CX201
Operations Common to Each Mode
●Setting the clock
2-1. Select “CLOCK”.
3-1. Press the [ROTARY] knob.
3-2. Press the [x] or [v] button to select the
hour or the minute.
3-3. Turn the [ROTARY] knob to set the correct
time.
∗ The clock is displayed in 12-hour format.
3-4. Press the [ROTARY] knob to store the time
into memory.
Note:
• You cannot set the clock when it is displayed
with only the ignition on. If you drain or remove
the car’s battery or take out this unit, the clock is
reset. While setting the clock, if another button or
operation is selected, the clock set mode is
canceled.
●Setting the contrast
You can adjust the display contrast to match the
angle of installation of the unit.
∗ The factory default setting is “10”.
(Adjustment level: 1 to 16)
2-1. Select “CONTRAST”.
3-1. Turn the [ROTARY] knob to adjust the
contrast.
● Setting the anti-theft function
(CATS)
“CATS” is the acronym of “Clarion Anti-Theft
System”. When you set a PIN code (called as
“Personal Code”), a theft is prevented by
disabling the operation of the unit at the theft.
• Setting your Personal Code
2-1. Select “CODE”.
3-1. Press the [ROTARY] knob.
The set personal code screen appears.
4-1. Press the [DIRECT] buttons [1]-[6] to enter
your desired 4-digit Personal Code.
5-1. Press and hold the [ROTARY] knob
(2 sec.).
The entered Personal Code will be set, and
it will return to the previous screen.
Note:
• Write down your Personal Code in case you
forget it.
•
Erasing the Personal Code
2-1. Select “CODE”.
3-1. Press the [ROTARY] knob.
The ERASE PERSONAL CODE screen
appears.
4-1. Enter the Personal Code currently.
5-1. Press and hold the [ROTARY] knob (2
sec.) or longer.
Entering a Personal Code mode is
cancelled.
To change adjustment setting
1. Press and hold the [DISP] button (1 sec.)
to switch to the adjustment selection
display.
2. Press the [x] or [v] button to select
the “item name”.
“CLOCK” ↔ “CONTRAST” ↔ “CODE” ↔
“SCRN SVR” ↔ “SCROLL” ↔
“DIMMER” ↔ “BLINKLED” ↔
“REAR/S-W” ↔ “INT-SW” ↔ “RESET”
3. Turn the [ROTARY] knob to select the
“desired setting value”.
∗ In the case of display blinking “ENT”, you
can press the [
ROTARY] knob to adjust the
setting v alue.
∗ After completing settings, press the [DISP]
button to return to the previous mode.
CX201_EN.book Page 21 Wednesday, November 17, 2010 10:50 AM
