Owner’s manual
•BASS BOOST, IMPACT, EXCITE Setting
: Select favorite setting mode from these presets and touch respective the [ - ] or [ + ] keys to
adjust the level.
“BASS BOOST” emphasizes low sound.
“IMPACT” weakens intermediate sound and emphasizes both low sound and high sound.
“EXCITE” weakens intermediate sound and emphasizes both low sound and high sound.
※ BASS BOOST - detail adjustments
SET BASS TREBLE
+3 F = 80Hz, G=+12dB, Q=1 F=12KHz, G= 4dB
+2 F = 80Hz, G=+10dB, Q=1 F=12KHz, G= 4dB
+1 F = 80Hz, G=+ 8dB, Q=1 F=12KHz, G= 4dB
0 F = 80Hz, G=+ 6dB, Q=1 F=12KHz, G= 4dB
-1 F = 80Hz, G=+ 4dB, Q=1 F=12KHz, G= 4dB
-2 F = 80Hz, G=+ 2dB, Q=1 F=12KHz, G= 4dB
-3 F = 80Hz, G=+ 0dB, Q=1 F=12KHz, G= 4dB
(1) Adjusting the Z-ENHANCER
① Press the [SOUND] button. (This button performs only when the panel is open.)
② Touch the desirable item key (Z-ENHANCER, BAL/FAD, OTHERS).
③ Perform the adjustment explaining in the following sections.
④ Touch the [BACK] key to return to the previous screen.
ITEM DEFAULT SETTING RANGE
Z-ENHANCER OFF ON or OFF
BASS BOOST 0 -3 ~ +3
IMPACT 0 -3 ~ +3
EXCITE 0 -3 ~ +3
