Jensen VM9021TS Car Stereo System User Manual



9
VM9021TS
Table 1: Front Zone Remote Control Functions
Button Function
Name Ref# DVD VCD TUNER CD/MP3 TV XM iPod
MENU 1 Enters the main menu of
the disc
Turns on PBC when play-
ing VCD
Displays XM Setup Menu Selects Photo mode
TITLE 2 Enters the title menu of
the disc
Plays first ten seconds of
each chapter/title
Selects Music mode
MUTE 3 Toggles on/off audio out-
put
Toggles on/off audio out-
put
Toggles on/off audio out-
put
Toggles on/off audio out-
put
Toggles on/off audio out-
put
Toggles on/off audio out-
put
Toggles on/off audio out-
put
POWER/
4 Turns the power on/off Turns the power on/off Turns the power on/off Turns the power on/off Turns the power on/off Turns the power on/off Turns the power on/off
AUDIO 5 Changes the audio lan-
guage for disc playback
Selects Video mode
REPT A-B 6 Setup to repeat playback
from time frame A to time
frame B
Setup to repeat playback
from time frame A to time
frame B
REPT 7 Repeats playback of cur-
rent chapter
Repeats playback of cur-
rent chapter
Repeats playback of cur-
rent track
Selects Category Mode Repeats playback of cur-
rent track
SRC 8 Selects playing mode Selects playing mode Selects playing mode Selects playing mode Selects playing mode Selects playing mode Selects playing mode
SUBTITLE 9 Language selection for
subtitle
INFO 10 Displays playing informa-
tion
Displays playing informa-
tion
Displays playing informa-
tion
Display playing informa-
tion
Displays playing informa-
tion
Displays playing informa-
tion
Displays playing informa-
tion
ANGLE
11 Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
angle of TFT screen
Continuously adjusts
angle of TFT screen
Continuously adjusts
angle of TFT screen
ANGLE
12 Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
front panel tilt angle
Continuously adjusts
angle of TFT screen
Continuously adjusts
angle of TFT screen
Continuously adjusts
angle of TFT screen
ANGLE 13 Plays back disc in differ-
ent angle for a scene
Plays back Picture CD
with different angle of
picture displayed
14 Fast forwards the disc
content
Fast forwards the disc
content
Fast forwards the disc
content
Accesses iPod Menu
VOL - 15 Decreases volume Decreases volume Decreases volume Decreases volume Decreases volume Decreases volume Decreases volume
VOL + 16 Increases volume Increases volume Increases volume Increases volume Increases volume Increases volume Increases volume
17 Selects the previous
chapter for playback
Selects the previous
chapter for playback
Searches an available
radio station by decreas-
ing tuning frequency
Selects the previous
track for playback
Searches an available TV
station by decreasing tun-
ing frequency
Searches an available
radio station by decreas-
ing tuning frequency
Pauses playback/starts
playback
18 Pauses playback/starts
playback
Pauses playback/starts
playback
Scans FM/AM radio sta-
tion; plays/stores radio
station; deletes radio sta-
tion
Pauses playback/starts
playback
Scans TV station; plays/
stores TV station; deletes
TV station
Scans XM radio station;
plays/stores radio sta-
tion; deletes radio station
19 Selects the next chapter
for playback
Selects the next chapter
for playback
Searches an available
radio station by increas-
ing tuning frequency
Selects the next track for
playback
Searches an available TV
station by increasing tun-
ing frequency
Searches an available
radio station by increas-
ing tuning frequency
Selects the next track for
playback
BAND 20 Stops playback Stops playback Selects FM/AM band Stops playback Selects XM, XM1, XM2,
or XM3 band
