Label Description
7 Paper-width and paper-length guides for the
photo tray
8 Paper-length guide for the main input tray
9 Photo tray
10 Ink cartridge door
11 Front USB port for your camera or other storage
device
12 Memory card slots and Photo light
13 Control panel
14 Glass
15 Lid backing
16 Ethernet port
17 Rear USB port
18 Power connection
*
19 1-LINE (fax) and 2-EXT (phone) ports
20 Two-sided printing accessory
* Use only with the power adapter supplied by HP.
Control panel overview
This section describes the functions of the control panel buttons and lights, as well as the
icons and sleep state on the display.
This section contains the following topics:
Control panel features
Display icons
Display sleep state
Chapter 2
(continued)
12 HP All-in-One overview
Overview
