13-EN
Displaying the Disc Status (DVD only)
Use the procedure described below to display the status (title number,
chapter number, etc.) of the currently playing DVD on the monitor
screen.
During playback, press DISPLAY.
The playback status is displayed for 5 seconds.
Displaying the Disc Status (Video CD only)
Use the procedure described below to obtain an on-screen display of
the status (track number, etc.) of the currently playing video CD on
the monitor screen.
During playback, press DISPLAY.
The playback status is displayed for 5 seconds.
9
PTRDISC
BC OPN
13'56"
DISC
NTSC VCD
TITLE
D
CDVIDEO
VD
TV system
(NTSC or PAL) Playback disc
Current track
number
Track playback
time
Repeat setting
(Default setting -
repeat off)
Playback control
(PBC)
116
PTR TITLE
:
:
:
UDIOADOLBYD3/2.0 1/
3
SUBT. JAPANESE 01/0
4
ANGLE 1/1
0018'56"
DISC
NTSC DVD
TITLE
D
DVD VIDEO
VD
TV system
(NTSC or PAL) Playback disc
Current title
number
Current chapter
number
Chapter
playback time
Current audio
number
Current subtitle
number
Repeat setting
(Default setting -
repeat off)
Audio recording
system
Current subtitle
language
Current angle
number
To Output DVD Video While Listening to
Another Source (CD/radio etc.) (only when
using Ai-NET)
When the DVA-5210 is connected to an Ai-NET compatible head unit
or Ai-NET compatible AV head unit, DVD video can be output
independently on the monitor.
If the rear monitor is connected, DVD video and audio can be output
independently on the rear monitor.
For example, DVD video can be output on the front or rear monitor,
while listening to the CD/radio from the head unit.
1
Change the source on the head unit or AV head
unit’s to CD or radio, etc.
2
Select the DVD image from this unit with the V.SEL
button (use the Simultaneous Function) on the AV
head unit or front monitor.
3
Press V.OUT on the remote control for this unit.
You can watch the DVD/video CD.
4
After using this function, press V.OUT to deactivate
the video output mode.
To watch the DVD on the rear monitor
5
See “Rear Monitor Select Function (AUX OUT)” in
the AV head unit or front monitor’s owner’s manual
to select the DVD image from this unit.
Caution
If the power or the ignition key is turned off without canceling the
video output mode, the set will start up in the video output mode
the next time the power is turned on, and the DVA-5210’s power
will remain on even if the source is switched with the head unit/
AV head unit or if you try to turn off the power of the DVA-5210.
If this happens, press V.OUT to cancel the video output mode.
• If the monitor has no rear monitor select function, the rear monitor
cannot be connected.
• Buttons to operate, etc., vary depending on the product. Refer to
the owner’s manual of the connected product for details.
