19-EN
P ARENTAL LEVEL OFF
PASSWORD CHANGE
∗∗∗∗
;
RETURN
PARENTAL
LSETUP
2 Use the number keys “0” to “9” to input the 4-digit
password, then press ENT.
PARENTAL
∗ ∗ ∗ ∗
Input numbers are displayed as “∗.“
The default password is 1111 upon shipment from the
factory.
The restriction level (PARENTAL LEVEL) input display
appears.
• Can be erased one digit at a time each time CLR is pressed. Press
CLR for at least 2 seconds to delete all digits.
•Press RETURN to return to the previous screen.
• If the password is wrong, the unit returns to the SETUP display.
3Press 8 or 9 to select the “PARENTAL LEVEL”.
4Press ;, : or ENT. to select the restriction level (1 to
8), then press ENT.
Select “OFF” to cancel the parental lock or if you do not
want to set a rating level.
The lower the number, the higher the rating level.
•Press RETURN, or press 8 or 9 to select “RETURN,” then press
ENT. to return to the previous display.
5Press SETUP.
The settings are stored and the setup mode is
deactivated.
• If you want to change the password, select “PASSWORD
CHANGE,” then input the new password (4 digits).
• Write down the password on a piece of paper and store the piece of
paper somewhere in case you forget it.
• On unrated DVDs, playback will not be restricted even if the rating
level is set.
• Once set, this rating level remains in memory until changed. To
enable the play of discs of higher rating levels or to cancel the
parental lock, the setting must be changed.
• Not all DVDs provide a Parental Lock feature. If you are unsure
about a DVD, play it first to confirm. Do not leave DVDs
accessible to young children for whom you deem them
inappropriate.
Tips
• Changing the rating level temporarily
Some discs may request that you change the rating level set
in the default settings during playback. In this case, the
message appears on the monitor screen “PARENTAL
LEVEL CHANGE OK?”
• To change parental level and play, press ENT.
• To play without changing the parental level, press L.
(When L is pressed, playback will be at the parental level
set with “Setting Parental Lock.” )
16:9 (WIDE)
Select this when
connected to a wide
screen TV. This is selected
upon shipment from the
factory.
4:3 LB (LETTER BOX)
Select this when connected to a
conventional 4:3 size (normal TV
aspect ratio) monitor. There may
be black bands visible at the top
and bottom of the screen (when
playing a 16 : 9 size movie). The
width of these stripes will depend
upon the original aspect ratio of the theatre release of the
movie.
4:3 PAN (PAN- SCAN)
Select this when connected
to a conventional 4:3 size
monitor. The picture will fill
the entire TV screen.
However, due to the
mismatch in aspect ratio,
parts of the movie at the
extreme left and right sides will not be visible (when playing a
16 : 9 size movie).
Setting the Country Code
Set the country code when setting the rating level (Parental lock).
Setting item: COUNTRY CODE
Setting contents: CODE
1Press 8 or 9 to select “COUNTRY CODE,” then press
ENT.
“COUNTRY CODE” will be reset.
COUNTRY CODE
- - - -
2 Use the number keys “0” to “9” to input the 4-digit
country code, then press ENT.
Example: Germany “6869” is input
COUNTRY CODE 6 8 6 9
• If the input code is wrong, “CODE ERROR” is displayed and the
unit returns to the setup display again.
•For the country codes, refer to “List of Country Codes” (Pages 26
to 27).
• Can be erased one digit at a time each time CLR is pressed. Press
CLR for at least 2 seconds to delete all digits.
•Press RETURN to return to the previous screen.
Setting the Rating Level (Parental Lock)
Use this function to restrict the viewing of movies to children of
appropriate age levels only.
Setting item: PARENTAL
Setting contents: Password
1Press 8 or 9 to select “PARENTAL,” then press ENT.
The password input mode is activated.
