9-EN
* The illustration is for CDE-W235BT.
* The illustration is for CDE-W233R.
Accessory List
Head Unit ..................................................................................1
Power Cable..............................................................................1
Microphone (CDE-W235BT only).............................................1
Mounting Sleeve ......................................................................1
Bracket Key...............................................................................2
Face Plate ..................................................................................1
Rubber Cap ...............................................................................1
Hex Bolt.....................................................................................1
Screw (M5 × 8) ..........................................................................4
Owner’s Manual..................................................................1 set
Turning Power On and Off
Press SOURCE to turn on the unit.
Note
The unit can be turned on by pressing any other button except .
Press and hold SOURCE for at least 2 seconds to turn
off the unit.
Note
The first time power is turned on, the volume will start from level 12.
Source Selection
Press SOURCE to change the source.
TUNER DISC USB AUDIO/IPOD
*1
BT AUDIO
*2
AUXILIARY
*3
TUNER
*1 Only when the iPod/iPhone is connected.
*2 Only for CDE-W235BT.
Only when BT AUDIO is set to ON. Refer to “Setting the
BLUETOOTH Connection (BT IN)” on page 26.
*3 Only when AUX SETUP is set to ON. Refer to “Setting the AUX
SETUP Mode” on page 23.
Initial System Start-Up
Be sure to press the RESET button when using the unit for the first time,
after changing the car battery, etc.
1
Turn off the unit power.
2
Press RESET with a ballpoint pen or similar pointed object.
Adjusting Volume
Turn the Rotary encoder until the desired sound is
obtained.
Getting Started
SOURCE/
/ENTER
Rotary encoder
AUDIO/SETUP
SOURCE/
/ENTER
Rotary encoder
SETUP
RESET button
