9-EN
2
Press
/ENTER
to display the Program Type screen.
3
Rotate the Double Action encoder to select a
program, and press
/ENTER.
The selected program is received.
Program Service example:
Changing the Display (HD Radio mode
only)
Press VIEW.
Every time VIEW is pressed changes the display.
* You can set a long or short HD Radio station name. Refer to “HD
Radio Station Call Setting” (
page 23).
When an iPod is connected to the iDA-X100 by using the proper cable,
the controls on the iPod are not functional.
The iPod is connected two different ways depending on the iPod model.
The USB connection is designed for the newest iPods. For older iPods,
use the FULL SPEED™ connection cable (KCE-422i).
• Only 5th generation iPod and iPod nano can be connected
via a USB device.
• If an iPod is connected via USB, the alphabet skip function
and the artwork screen can be displayed.
• If an iPod is connected via Full Speed™ (KCE-422i), set
AUX+ Setup to OFF. AUX+ cannot be used if an iPod is
connected (refer to “Setting the AUX+ Mode” on
page 21).
• If the Bluetooth Box and an iPod are connected at the same time, be
sure to disconnect the iPod from Bluetooth Box while turning ACC to
OFF.
About iPods usable with this unit
• The unit can be used with the following iPod.
<USB connected>
Fifth generation iPod
First generation iPod nano
Second generation iPod nano
<Connected via Full Speed™>
Fourth generation iPod
Fifth generation iPod
iPod photo
iPod mini
First generation iPod nano
Second generation iPod nano
• If the unit is used with iPod software versions of iTunes later
than 7.4.3.1, correct function and performance are not
guaranteed.
• Touch wheel or scroll wheel type iPods without the dock
connector cannot be connected to the unit.
• The usage of iPod Shuffle with this unit is not supported.
Multicast Radio Station Program No. Program Service
88.8MHz No.1
MPS
: Main Program Service
88.8MHz No.2 SPS: Sub-program Service
88.8MHz No.3 SPS: Sub-program Service
·
·
·
88.8MHz No.8 SPS: Sub-program Service
Song title
Artist title
Album title
Frequency
Station Call
Letter
*
Calendar/
Time
Song title
Artist title
Album title
Frequency
iPod
®
FUNC./SETUP
SOURCE
/
/ENTER
Double Action encoder
VIEW
