Alpine IDA-X100 Car Stereo System User Manual



20-EN
Use the SETUP menu to flexibly customize the unit to suit your own
preferences and usage. Choose settings from General, Display, etc., to
make the desired changes.
1
Press and hold FUNC./SETUP for at least 2
seconds to activate the SETUP selection mode.
2
Rotate the Double Action encoder to select the
desired item, and then press
/ENTER.
Bluetooth General Display iPod XM* SIRIUS*
HD Radio*
Audio
(e.g. Select General)
* Only when HD Radio Tuner / SAT receiver is connected.
3
Rotate the Double Action encoder to select a
setting item, and then press
/ENTER.
(e.g. Select Beep)
Bluetooth:
Bluetooth IN
General:
Clock Mode Clock Adjust
*
1
Calendar Type Daylight
Time Play Mode Beep Int Mute Int Audio
CHG Name
*
2
AUX IN AUX+ AUX Name
*
3
AUX+
IN GAIN
*
4
Power IC Language Demo
Display:
Illumination Dimmer Dimmer Level Text Scroll
BGV Select BGV Color
BGV Download
iPod:
Playlists Artists Albums Podcasts Audiobooks
Genres Composers Songs
XM*
5
:
XM ADF
SIRIUS*
5
:
Game Alert
HD Radio*
6
:
Station Call Digital Seek
Audio*
7
:
User Preset MX*
8
Subwoofer*
8
Subwoofer System*
9
MX Level Adjustment*
8
*
10
*
1
Refer to “Setting the Time and Calendar” (page 6).
*
2
The setting can be made only when a changer is connected.
*
3
The setting can be made only when AUX IN is set to ON.
*
4
The setting can be made only when AUX+ is set to ON.
*
5
Displayed only when SAT radio receiver is connected.
For the SAT Radio Setting, refer to “SAT Radio Receiver (Optional)”
(
page 24).
*
6
Displayed only when HD Radio TUNER MODULE (TUA-T500 HD)
is connected.
*
7
If IMPRINT audio processor is connected, you can make more
detailed settings for the audio setting. For details, refer to “IMPRINT
Operation (Optional)” (
page 29).
*
8
The adjustment can be made only when an external audio processor is
connected. Refer to the Owner’s Manual of the external audio processor.
*
9
The setting is available only when Subwoofer is set to ON.
*
10
The setting is available only when MX is set to ON.
4
Rotate the Double Action encoder to change the
setting, and then press
/ENTER.
(e.g. Select Beep On or Beep Off.)
5
Press and hold for 2 seconds to return to normal
mode.
Pressing during the procedure will return to the previous mode.
During setup, if you press in the outer ring and rotate the Double
Action encoder to the left or right, the setting item selection screen
changes page by page. If you press then rotate and hold the Double
Action encoder to the left or right, the setting item selection screen
continuously changes page by page.
Select Bluetooth from the setup main menu in step 2 above.
If an optional Bluetooth Box is connected, you can place a hands-free
call by a Bluetooth- equipped mobile phone.
Make this setting when the Bluetooth Box is connected and the
Bluetooth function is used. For details, refer to the Owner’s Manual of
the optional Bluetooth Box.
When Int Mute is set to On, the Bluetooth setting cannot be made.
When the Bluetooth box is connected, set Int Mute to Off. Refer to
“Turning Mute Mode On/Off (Int Mute)” (
page 21).
Setting the Bluetooth Connection
SETUP
Follow steps 1 to 5 to choose an item to change. See
the individual item descriptions following Step 5 for
further details.
Double Action encoder
PRESET
BAND
/ENTER
SOURCE
FUNC./SETUP
Bluetooth Setting
Bluetooth IN Adapter / Bluetooth IN Off (Initial Setting)
