21-EN
General is selected on the setup main menu in step 2.
Setting the Clock Display (Clock Mode)
You can select the clock display type, 12-hour or 24-hour, depending on
your preference.
Setting of Calendar Display Pattern Switching (Calendar Type)
You can switch the calendar display pattern to be shown when the time
is displayed.
ex. M/D/Y Dec/31/2008
Setting Daylight Saving Time (Daylight Time)
Connecting an MP3 Changer (Play Mode)
Perform this setting when connecting MP3 changer. MP3 changer can
playback CDs containing both CD and MP3 data. However, in some
situations (some enhanced CDs), playback may be difficult. For these
special cases, you can select playback of CD data only. When a disc
contains both CD or the MP3 data, playback starts from the CD data
portion of the disc.
Change discs after performing this setting.
Sound (Beep) Guide Function
This function will give audible feedback with varying tones depending
upon the button pressed.
Turning Mute Mode On/Off (Int Mute)
If a device having the interrupt feature is connected, audio will be
automatically muted whenever the interrupt signal is received from the
device.
When Bluetooth is set to Adapter, Int Mute cannot be set. Refer to
“Setting the Bluetooth Connection” (
page 20).
When the Bluetooth box is connected, set Int Mute to Off.
Setting Tone Defeat for External Devices (Int Audio)
When inputting external devices to this unit, turning tone defeat on will
bypass Bass Frequency, Treble Frequency, High Pass Filter, i.e., sound
for external devices is output at the default setting.
Setting the Changer Name (CHG Name)
When an optional changer is connected, you can set the displayed mode
name.
The setting can be made only when a changer is connected. When
two changers are connected, the CHG1 Name/CHG2 Name is
displayed, and the setting can be made respectively.
Setting the AUX Mode (V-Link)
You can input TV/video sound by connecting an optional Versatile Link
Terminal (KCA-410C) to this component.
You can change the AUX name display when AUX IN is set to On.
When AUX IN is set to On, select the AUX Name mode by rotating the
Double Action encoder , then press
/ENTER.
After that, rotate the Double Action encoder to select the desired AUX
name, then press
/ENTER.
If the KCA-410C is connected, it is possible to select two AUX names.
Via KCA-410C, up to 2 external devices with RCA output can be
connected. In this case, press
SOURCE to select AUX mode and
then press BAND to select your desired device.
Setting the AUX+ Mode
You can input the audio of a connected external device, (such as a
Portable audio player) to the Full Speed
TM
connector of this unit, using
an iPod Direct/RCA Interface cable (KCE-236B).
AUX+ Audio Level Adjustment (AUX+ IN GAIN)
General Setting
24H Type / 12H Type (Initial setting)
M/D/Y (Initial setting) / D/M/Y / Y/M/D
Y : shows the year
M : shows the month
D : shows the day
On / Off (Initial setting)
On: Turn Daylight Saving Time mode ON. The time
advances by one hour for areas observing Daylight
Saving Time.
Off: Return to the ordinary time.
CDDA (Initial setting) / CDDA & MP3
CDDA : Only CD data can be played back.
CDDA & MP3 :Both CD data and MP3 file tracks can be played
back.
Beep On (Initial setting) / Beep Off
Int Mute On (Initial setting) / Int Mute Off
Int Audio On / Int Audio Off (Initial setting)
CHG (Initial setting) / PMD
AUX IN On / AUX IN Off (Initial setting)
AUX+ On / AUX+ Off (Initial setting)
AUX+ On : Set to On when an external device is connected. If
SOURCE is pressed and Auxiliary+ is selected,
the sound of the external device is input to the unit.
AUX+ Off : Set to Off when an iPod is connected.
High (Initial setting) / Low
Low: Decreases the external input audio level
High: Increases the external input audio level
