14-EN
NOTES
When the speaker is set to the OFF mode, the
parametric equalizer for that speaker is ineffective.
Refer to Setting the speakers (page 4).
It is not possible to adjust the frequencies of adjacent
bands within 7 steps.
Check the playable frequency ranges of the connected
speakers before making the equalizer adjustments. If
the speaker's playable frequency range is 55 Hz to 30
kHz, for example, adjusting the 40 Hz or 20 Hz band
has no effect. Additionally, you may overload and
damage the speakers.
After making the settings, we recommend storing
them in the memory. For instructions, see page 28.
When parametric EQ is adjusted, the adjustment for
graphic EQ becomes ineffective.
Settings/Adjustments
9 Repeat steps 5 to 8 to adjust other bands.
10
To adjust other channels, press the CHANNEL
button to return to step 4.
* To compare the factory default settings
(DEFEAT ON) with your newly adjusted
parametric equalizer settings (DEFEAT
OFF), do the following:
1) While in the adjustment mode, press and
hold the P.EQ button for at least 2 seconds.
2) Press the P.EQ button to switch the defeat
mode on and off and listen to the difference
in the sound.
3) To quit, select the desired setting, then press
the ENTER button.
Note that if you press the ENTER button with
the defeat mode turned on, the adjustments
are reset to the defeat on status (the default
values).
11
Once the adjustments are completed, press the
P.EQ button.
CHANNEL
ENTER
P.EQ
