8 VMA8582 (U)
English
Owner’s Manual
Display Unit
Dimmer sensor
When AUTOMATIC DIMMER is selected in
dimmer setting, the brightness of the screen is
adjusted automatically according to the
ambient brightness.
STAND BY (R), ON(G)
When the power is
turned off..........red color
When the power is
turned on..........green color
Receiver for remote
control unit
Built-in speaker
(on the back panel)
The screw hole is provided to install a TV stand at the bottom of this monitor.
(1/4 inch unified screw thread, 4.5 mm of maximum length)
Terminal to which
cables from the
control box are
connected. (on the
right side of the
monitor)
Precautions on handling of the LCD panel
• Do not leave the monitor on the dashboard with the LCD panel facing upwards. (Range of storage
temperature: -20˚C to +80˚C)
When the temperature is high or low, chemical changes occur in the LCD panel, resulting in damage
to the monitor.
• Since the LCD panel has been specially processed, the fingerprints will remain on the panel and
stand out if you touch the panel. Avoid touching the panel as much as possible. Also avoid pushing
the panel.
• When temperature becomes low, the picture does not appear or sometimes it takes time to appear.
On occasion, the picture motion seems to be different from that at normal temperature and the
picture quality deteriorates. These phenomena are not a malfunction. (Range of operating tempera-
ture: 0˚C to +40˚C)
• On the panel red dots, blue dots and green dots are found. This is peculiar to the LCD panel and it is
not a malfunction.
[The LCD panel has been designed and manufactured using a highly developed precision technol-
ogy and has a 99.99 % or more effective pixels. However, note that 0.01 % of pixels are defective
and always light.]
CAUTION
