BASIC OPERATION
18. MOD BUTTON
Press it repeatedly to select DISC, AUX IN or RADIO mode.
19. EJECT BUTTON
Press the eject button to eject the disc from the disc slot.
20. FLASHING LED
If the front panel is not on the main unit, LED will be flashing.
21. RESET BUTTON
RESET button is placed on the housing and must be activated with either a ballpoint
pen or thin metal object. The RESET button is to be activated for the following
reasons:
-Initial installation of the unit when all wiring is completed.
-All the function buttons do not operate.
-Error symbol on the display.
Note: If press RESET button, the unit can’t work yet, please use a cotton swab
soaked in isopropyl alcohol to clean the socket on the back of the front panel.
22. ST BUTTON
Press ST button to select stereo or mono reception for radio stations.
MP3 DISC PLAY
1. MP3 disc is playing as the format of FOLDER by FOLDER.
For example:
Use
/ / / to select the item or folder, then press ENTER button.
Pressing REPEAT button repeatedly can select three kinds of repeat play mode.
2. REP-ONE:
Play the same song over and over again.
3. FOLDER REPEAT:
Play all songs in the current directory in sequence, over and over again.
4. DISC REPEAT:
Play all songs in the disc over and over again.
In the playback, use
or to skip an item ahead or back.
When long pressing the / to fast rapid forward/reverse.
Note: The FOLDER cannot be selected during playing. It can be selected after
(Stop) button pressed.
ROOT 0
MP3 MUSIC 1
SKY
MP3 HEAR YOUR
ROOT
MP3 PLAYER
18. MOD BUTTON
Press it repeatedly select DISC, AUX IN, RADIO mode. In USB playing , you can
press the stop button to stop playing , then press GOTO button to display the DVD
dire and USB dev on the screen, press UP/DN button to select the DVD dire to select
the DVD mode , then playing the DVD disc.
19. EJECT BUTTON
In CDP playing, press the eject button to eject the disc form the disc slot. If in USB
playing , you must change the mode to the DVD mode to eject the disc, otherwise,
you cannot eject the disc from the disc slot.
20. FLASHING LED
If the front panel is not on the main unit, LED will be flashing.
21. RESET BUTTON
RESET button is placed on the housing and must be activated with either a ballpoint
pen or thin metal object. The RESET button is to be activated for the following
reasons:
-Initial installation of the unit when all wiring is completed.
-All the function buttons do not operate.
-Error symbol on the display.
Note: If press RESET button, the unit can’t work yet, please use a cotton swab
soaked in isopropyl alcohol to clean the socket on the back of the front panel.
22. ST BUTTON
Press ST button to select stereo or mono reception for radio stations.
MP3 DISC PLAY
1. MP3 disc is playing as the format of FOLDER by FOLDER.
For example:
Use
/ / / to select the item or folder, then press ENTER button.
Pressing REPEAT button repeatedly can select three kinds of repeat play mode.
2. REP-ONE:
Play the same song over and over again.
3. FOLDER REPEAT:
Play all songs in the current directory in sequence, over and over again.
4. DISC REPEAT:
Play all songs in the disc over and over again.
In the playback, use
or to skip an item ahead or back.
When long pressing the
/ to fast rapid forward/reverse.
Note: The FOLDER cannot be selected during playing. It can be selected after
(Stop) button pressed.
ROOT 0
MP3 MUSIC 1
SKY
MP3 HEAR YOUR
ROOT
MP3 PLAYER
