REMOTE CONTROL
CLK
OSD
BAND POWER
SLOW
TITLE/PBC
MO/ST
LO/DX
EQ
15
21
17
23
25
14
16
18
20
24
2
4
10
8
13
6
5
1
7
11
3
MUTE
PLAY/PAUSE
A/P
STOP
SETUP
ANGLE
REPEAT
GOTO
SEL
3214
MENU +10
MODE
ENTER
7658
09
22
19
9
VOL+
VOL-
12
SW
1. CLK Press it to change the display to clock display.
2. MODE Press it to change between radio or disc mode.
3. STOP Press it to stop playback.
4. SETUP Display the SETUP menu.
5. MO/ST Press it to select STEREO or MONO (In disc stations, press it to
(AUDIO) changing of the AUDIO soundtrack on multi-audio soundtrack DVD
disc. Changing of the sound mode of the VCD/CD disc)
6. LO/DX Changing of the SUBTITLE language on multi-subtitle language
(SUBTITLE) DVD disc. In radio mode, press this button for distance reception
when you are located at weak signal location, depress it for stronger
signal.
7. REPEAT Switch the Repeat mode of DVD/VCD/CD disc.
8. GOTO Disc search button, cooperatively used with numeric buttons
9.
/ Press to skip to the next track & press to skip back one track.
10. SEL Press it to change audio mode through Volume, Bass, Treble, Balance
and Fader modes.
11. VOL+/VOL- Press it to adjust volume level.
12.
/ / / Cursor buttons in MENU mode.
13. MENU/ Press it to display the root menu of the DVD disc./ Press and hold for
SUBWOOFER
more than 2 seconds can have subwoofer.
14. BAND(OSD) Display statistical disc information during playback (To change the
band in radio stations)
15. POWER Press it to turn on the unit, press it again to turn off.
16.
PLAY/PAUSE
Press once to pause a play, press again to resume playback.
17. MUTE Press it to mute down sound.
18. TITLE/PBC Display the TITLE menu that is stored in DVD disc changing
(A/P) between PBC ON and PBC OFF on the VCD disc. (Auto store and
preset scan function in radio stations.)
19. SLOW Changing for slow forward/reverse playback motion.
20. ANGLE Changing of the view angle on multi-angle DVD disc
21. EQ Press it to turn to equalization function.
22.
/ Press to start forward rapidly & to reverse rapidly.
23. ENTER Confirm the Track/Chapter selected with the number key or selected
with the cursor buttons on TV screen.
24. 0 - 9 Numeric buttons
25. +10 Press it to select 10th digits
