INSTALLATION
DASH BOARD
HEX NUT
SPRING WASHER
PLAIN WASHER
TAPPING SCREW
METAL MOUNTING STRAP
CONSOLE
SLIDE BRACKET HOUSING
HEX BOLT
KEY PLATE
PLASTIC TRIM OUT
KEY PLATE
FRONT PANEL
1. WHILE INSTALLING THE FRONT PANEL, PLEASE MOUNT THE LEFT SIDE FIRST, AND MAKE THE
DIRECTION HOLE ON THE FRONT PANEL AIM AT THE LEFT GUIDE ON THE UNIT.
2. THEN PUSH THE RIGHT SIDE TO MOUNT THE RIGHT GUIDE.
3. PUSH IT TO INSTALL THE FRONT PANEL COMPLETELY.
