16
Adjustment Using the Menus
3 Select an item.
Press the M or m button to select the item, then press the ,
or ENTER button.
The item to be changed is displayed in yellow.
Note
If the menu consists of multiple pages, press M or m to go to
the desired menu page.
4 Make the setting or adjustment on an item.
When changing the adjustment level:
To increase the number, press the M button.
To decrease the number, press the m button.
Press the ENTER button to confirm the number, then restore
the original screen.
When changing the setting:
Press the M or m button to change the setting. Press the
ENTER button to confirm the setting.
Notes
• An item displayed in blue cannot be accessed. You can
access the item if it is displayed in white.
• If the key inhibit has been turned on, all items are
displayed in blue. To change any of the items, turn the key
inhibit to OFF first.
For details on the key inhibit, see “KEY INHIBIT menu” (page 19).
To clear the menu
Press the MENU button.
The menu disappears automatically if a button is not pressed for
one minute.
About the memory of the settings
The settings are automatically stored in the monitor memory.
To reset items that have been adjusted
Pressing the RESET button while you are adjusting any of the
menu items resets the menu item to the previous setting.
Adjustment Using the
Menus
Items
The screen menu of this monitor consists of the following items.
STATUS (the items indicate the
current settings.)
FORMAT
COLOR TEMP
GAMMA
COMP LEVEL
NTSC SETUP
RGB/COMP SEL
SCAN MODE
DISPLAY
OPTION
COLOR TEMP/BAL
COLOR TEMP
MANUAL ADJ
USER CONTROL
CONTROL
USER CONFIG
RGB/COMP SEL
COMP LEVEL
NTSC SETUP
GAMMA
FORMAT DISP
LANGUAGE
MARKER
CENTER MARKER
MARKER LEVEL
SCAN
PIC DELAY MIN
REMOTE PARALLEL
1PIN
2PIN
3PIN
4PIN
6PIN
7PIN
8PIN
KEY INHIBIT
KEY INHIBIT
