Location and Function of Parts and Controls
m LINE A button
Press to monitor the signal through the LINE A input connector.
n Speaker
The audio signal selected by the input select button (j SDI
button, k RGB/COMPONENT button, l HDMI button or
m LINE A button) on the front panel is output.
Input Signals and Adjustable/Setting Items
a : Adjustable/can be set
× : Not adjustable/cannot be set
*1 When a component signal (480/60I) is input, this can be switchable.
*2 When a 480/60P or 576/50P signal is input, this can be switchable.
*3 When an interlace signal is input, this can be switchable.
*4 When BKM-320D is used, SDI signals can be input.
*5 When a 1080I signal is input, this cannot be switched.
(PIC DELAY MIN is set to “ON” only.)
*6 When a PC signal is input to the HDMI IN connector using a DVI conversion
cable, this can be adjusted.
Input signal
Item Video, Y/C B & W Component RGB SDI
*4
HDMI
SD HD SD HD D1 SD HD DVI
*6
CONTRAST aaaaaaaaaa
BRIGHT aaaaaaaaaa
CHROMA a × aa××aaa×
PHASE a
(NTSC)
×××××××××
APERTURE aaaa××aaa×
COLOR TEMP aaaaaaaaaa
COMP LEVEL
*1
××
a
(480/60I)
×××××××
NTSC SETUP a
(NTSC)
a
(480/60I)
××××××××
GAMMA aaaaaaaaaa
SCAN aaaaaaaaa×
ASPECT aaaa
*2
aa
*2
aaa
*2
×
MARKER aaaaaaaaa×
BLUE ONLY a × aaaaaaa×
PIC DELAY MIN
*3
aaaa
*5
aa
*5
aaa
*5
×
EXT SYNC ××aaaa××××
